Generaltimers
22033 5611 1 T3T: Test on load end timer sec.
22034 5612 1 Limit_TOF: Test off load is limited
0: unlimited
1: limited
22035 5613 1 TFT: Test off load duration timer sec.
22036 5614 1 E1T: Time before external order on load sec.
22037 5615 1 E3T: Time after external order on load sec.
22038 5616 1 Limit_EOLTOT: External order on load is limited
0: unlimited
1: limited
22039 5617 1 E2T: External order on load duration sec.
22040 5618 1 E5T: Time before external order off load sec.
22041 5619 1 E7T: Time after external order off load sec.
22042 561A 1 Limit_EOFTOF: External order off load is limited
0: unlimited
1: limited
22043 561B 1 E7T: External order off load duration sec.
AnnexeII-18.SetupthresholdforupstreamVoltages
Function 3, 6 and 16 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
22272 5700 1 Source 1: Overvoltage threshold %
22273 5701 1 Source 1: Overvoltage hysteresis threshold %
22274 5702 1 Source 1: Undervoltage threshold %
22275 5703 1 Source 1: Undervoltage hysteresis threshold %
22276 5704 1 Source 2: Overvoltage threshold %
22277 5705 1 Source 2: Overvoltage hysteresis threshold %
22278 5706 1 Source 2: Undervoltage threshold %
22279 5707 1 Source 2: Undervoltage hysteresis threshold %
22280 5708 1 Source 1: Unbalanced voltage threshold %
22281 5709 1 Source 1: Unbalanced voltage hysteresis threshold %
22282 570A 1 Source 2: Unbalanced voltage threshold %
22283 570B 1 Source 2: Unbalanced voltage hysteresis threshold %
22284 570C 1 Source 1: Overfrequency threshold %
22285 570D 1 Source 1: Overfrequency hysteresis threshold %
22286 570E 1 Source 1: Underfrequency threshold %
22287 570F 1 Source 1: Underfrequency hysteresis threshold %
22288 5710 1 Source 2: Overfrequency threshold %
22289 5711 1 Source 2: Overfrequency hysteresis threshold %
22290 5712 1 Source 2: Underfrequency threshold %
22291 5713 1 Source 2: Underfrequency hysteresis threshold %
