Voltage adapters connection principle
U500dc,
U1000dc
U1500dc
Adapter
U-32dc
NC NC - +
- +
- NC NC +
- (0 V)
-
+
+
The U500dc, U1000dc, U1500dc voltage adapters only be connected to a U-32dc module.
