ACCUMULATOR AND INTERNAL GROUP EXPLODED VIEW
4
A.00010238
1
5
A.00010444
O-RING
1
6
A.00010527
SEAL
1
7
A.00010623
SEAL
1
8
A.00010648
SEAL
1
9
A.00014296
O-RING
10
A.00030562
ALLEN PLUG
2
11
B.0093040
PILOTING PISTON
2
12
B.0152040
BODY BUSH RING
1
13
B.0153010
DISTRIBUTOR BUSH
1
14
B.0172010
LOWER BODY BUSH
7
1
15
B.0172020
PISTON
1
16
B.0172050
UPPER BODY BUSH
1
17
B.0173010
DISTRIBUTOR VALVE
1
18
A.00010366
O-RING
1
19
A.00010371
SEAL
1
20
A.00030596
SCREW
10
21
A.00030599
SCREW
6
22
A.00053464
NITROGEN CHARGING VALVE
1
23
B.0094030
DIAPHRAGM
1
24
B.0164030
UPPER BUFFER
1
25
B.0174010
ACCUMULATOR BASE
1
26
B.0174020
ACCUMULATOR COVER
1
SEAL
Ref
Quantity
Code
Description
Spare parts
(Refer to the exploded views of the previous pages)
