22
MASTERYS BC 60-80 kVA - Ref.: IOMMASBCXX06-EN 06
5. MIMIC PANEL
5.1.4. Alarms menu
This menu displays all alarms that are active at the time of access. The alarms menu is activated automatically when an alarm condition occurs.
ALARMS menu
Code Mimic panel message Description
A00 GENERAL ALARM At least one alarm is present
A01 BATTERY ALARM Battery circuit failure or faulty operation
A02 OUT OVERLOAD Power required in output over the limits
A06 VAUX OUT OF TOL
The voltage or frequency limits accepted by the bypass have been exceeded
A07 OVER TEMPERATURE Temperature excessive or ventilation problems
A08 MAINTEN. BYPASS Active bypass procedure
A17 IMPROPER USE Improper conditions of use verifi ed (load, mains, temperature)
A18 OVERLOAD OFF INV Inverter shutdown due to overload
A20 WRONG CONFIG.
Error in the confi guration parameters (e.g. di erent between several UPS units in parallel)
A22 MAINS OUT OF TOL
The voltage or frequency limits accepted by the rectifi er have been exceeded
A23 RECTIFIER ALARM Rectifi er fault
A25 INVERTER ALARM Inverter fault
A26 BATT CHARGER ALM Battery charger fault
A29 BYPASS ALARM Bypass fault
A30 OVERLOAD STOP The duration of the overload has inhibited the bypass
A38 EXTERNAL ALARM1 Signalling from ADC input
A39 EXTERNAL ALARM2 Signalling from ADC input
A40 EXTERNAL ALARM3 Signalling from ADC input
A41 EXTERNAL ALARM4 Signalling from ADC input
A42 REMOTE SERVICE ALARM
This alarm indicates that a critical anomaly has occurred on the UPS.
Where a maintenance contract with the Remote Monitoring option is in
place, the procedure for analysing the UPS via remote connection will be
automatically activated by your service centre provider.
A43 REDOUNDANCY LOST
The power required by the load no longer allows the preset redundancy
N+x (signalling for UPS units in parallel) to be maintained
A44 SERVICE CHECK Notifi cation that the routine service check is overdue
A49 BATT. DISCHARGED The energy available in the battery has been depleted
A51 OPT. BOARD ALM Fault in the optional cards in the slots
A58 ESD ACTIVATED The remote emergency shutdown command has been activated
A59 BATT.CIRC. OPEN The battery switch is open
A60 FAN FAILURE Fans faulty or blocked
A61 PHASE ROT. FAULT Wrong phase cycle direction
