Sofamel HPS-130-H3 - Page 15

15
HPS-130-H3
Contents Page
1. Introduction
2. Labels
3. Warranty
4. Description of the manual hydraulic
compression tool
5. Instructions for proper use
5.1. Operation of the tool
Caution:
Do not operate the compression
tool without dies.
Before putting into operation your compres-
sion tool please read the operating instruc-
tions carefully.
Use this tool exclusively in the field of
application it is designed for.
Only specially trained persons are allowed
to mount and assemble connectors with the
help of this tool. The minimum age is 16
years.
The operating instructions have to be carried
along during the entire life span of the tool.
The operator has to
• ensure that the operating instructions are
available for the user
• make sure that the user has read and
understood the operating instructions.
1. Introduction .....................................................................................................................15
2. Labels...............................................................................................................................15
3. Warranty...........................................................................................................................15
4. Description of the manual hydraulic compression tool....................................................15
5. Instructions for proper use ...............................................................................................15
5.1. Operation of the tool ........................................................................................................15
5.2. Explanation of the application range................................................................................16
5.3. Mounting instructions.......................................................................................................16
5.4. Service and maintenance instructions .............................................................................16
5.5. Storage and transport of the compression tool...............................................................16
6. Troubleshooting................................................................................................................17
7. Putting out of service / disposal.......................................................................................17
8. Specifications...................................................................................................................17
9. Legend.............................................................................................................................17
Subject to proper use we grant a warranty
period of 12 months from the date of delivery.
The manual hydraulic compression tool
HPS-130-H3 is a handtool.
First select the appropriate pair of dies (1)
for the intended application.
After that, insert the compression dies one
after the other sideways into the die holders
until they engage centrally. For deep notch
compression remove the die holder (6) side-
ways from the comression head and insert
the adaptor (7) with the cage for deep
notch (8). On the opposite side insert arbor
(9) into the die holder (6). Then the connec-
tor is inserted into the crimping head.
On the pump you find a label with the type
designation, the name of the manufacturer,
the serial number and the specifications.
