Thereisdi󰘯erentfeed-inlimitationmodesavailable,whichcanbesetintheLCDscreen
menu:
Feed-in Limit menuFeed-in Limit menu
Feed-in ControlFeed-in Control Standard Mode. In case of a communication error with
the SmartMeter, the inverter limits its output power to the
setpoint.
Hard Feed-in ControlHard Feed-in Control When the Hard Feed-in Control is activated, the inverter
shuts down whenever the setpoint is exceeded.
Ctrl. Total PowerCtrl. Total Power Limit the power of the feeding-in phases to the setpoint.
Ignore the phases where energy is bought from the grid
(standard-setting).
Ctrl. Phase PowerCtrl. Phase Power Limit the feed-in power of the sum of all phases to the set-
point (i.e. Germany).
Ctrl. Selling PowerCtrl. Selling Power Limit the feed-in power of each phase to 1/3 of the setpoint.
System monitoringSystem monitoring
The SOFAR 100...125KTLX-G4 inverters provide various communication methods for
the system monitoring:
RS485 or WiFi stick (standard), GPRS or Ethernet stick (optional).
RS485 networkRS485 network
You can connect RS485-linked devices to your PC via an RS485 USB adapter or con-
nect them to a data logger.
• The RS485 line may not be any longer than 1000 m.
• Assign each inverter its own modbus address (1 to 31) via the LCD display.
• At the last inverter, put a termination resistor of 120 Ohm between RS485+ and
RS485-.
44/78 SOFAR 100...125KTLX-G4
Communication Connection
