INSTALLATION
EN - English Page 8
FILTER MANIFOLD TO AIR GAP ON DRINKING WATER
FAUCET
1. On the other end of the red polytube ¼”, coming from the
small barb fitting of the air gap of the drinking water
faucet (= side with label), make sure the drain flow control
is properly inserted (⑪).
2. Insert the end of the polytube in the push-fit connection
marked ‘W’, at the right side of the filter manifold; make
sure to push it in all the way; gently pull on the polytube
to verify it is secured.
AIR GAP ON DRINKING WATER FAUCET TO KITCHEN SINK
DRAIN
1. Insert the other end of the white polytube ⅜”, coming
from the large barb fitting of the air gap on the drinking
water faucet (⑨), in the push-fit connection of the drain
saddle on the discharge pipe of the sink; make sure to
push it in all the way; gently pull on the polytube to verify
it is secured.
