Solem BL-IS - Wiring the BL-IS Controller

4
Step 3
S S
Black
Black
CP
1. Connect the BL-IS to the solenoids as described below.
Use 24V valves only.
2. (Option) If you want to install a rain sensor, remove the yellow wire
of the BL-IS and connect the sensor to the terminals S.
WIRING
