After you have successfully joined your Wireless CCK to your home network you have two options
for placement.
OPTION 1:
1. If you have an open port on your splitter and do not want it in the same room as a DIRECTV
receiver:
2. Make sure the CCK is plugged into a power outlet and both the POWER and WLAN lights
are green.
3. Connect a cable from the splitter to the “To LNB” port on the CCK.
4. Make sure the “Satellite Receiver” connector on the CCK is capped off.
OPTION 2:
1. If you want to leave it in the same room as your DIRECTV receiver:
2. Disconnect the satellite line from the receiver.
3. Make sure the CCK is plugged into a power outlet and both the POWER and WLAN lights are
green.
4. Uncap the “Satellite Receiver” connector on the CCK.
5. Use the short coaxial cable to connect the Satellite Receiver port to your receiver’s “Satellite 1”
port (or if there is only one port, use that.)
When the system is properly connected you should have four green lights.
The AP/STA light is not used.
The following diagram shows step 2 of the installation procedure.
INSTALLING A WIRELESS
CINEMA CONNECTION KIT (STEP 2)
