Solid Signal DECA BROADBAND - PROVIDING ETHERNET USING A DECA; DECA;DECA BROADBAND ETHERNET DIAGRAMS

Project: Coax Networking
DOCUMENT DATE: January, 2014
©2014, SolidSignal.com Reproduction is permitted as long as copyright information is intact.
©2014, SolidSignal.com Reproduction is permitted as long as copyright information is intact.
Use a DECA Broadband or receiver DECA to connect all your devices
PROVIDING ETHERNET USING A DECA
OPTION 1: For HR24, H24, and H25, as well as Genie DVRs
OPTION 2: For HR20, HR21, HR22, HR23, H21, H23, R22, and THR22 (TiVo) receivers
Connected
devices
to Dish or Switch
Note: Power adapters are not shown.
Network Switch
Connected
devices
to Dish or Switch
Green
label
splitter
To
AC
Power
Note: Power adapters are not shown.
Network Switch
DIRECTV
IN
OUT OUT
DC POWER PASS
DIRECTV
CONNECTED HOME
ADAPTER
DIRECTV
CONNECTED HOME
ADAPTER
EPS10
Power Adapter
