Solid State Logic XLogic Alpha VHD Pre Unit User Manual

Physical *
Depth 230mm / 9" casing only
Height 44.5mm / 1.75" (1 RU)
Width 438mm / 17.25" casing only
482mm / 19" inc’ rack ears
Weight 2.6kg / 6 pounds
Power < 20 Watts
Boxed size 320mm x 550mm x 80mm
12.75" x 21.75" x 3.25"
Boxed weight 3.5kg / 8 pounds
* All values are approximate
Environmental
Temperature Operating: +5 to 30 deg. C
Non-operating: –20 to 50 deg. C
Max. gradient: 15 deg. C/hour
Relative Operating: 20 to 80 %
Humidity Non-operating: 5 to 90 %
Max. wet bulb: 29 deg. C
(non-condensing)
Vibration Operating: < 0.2 G (3 – 100Hz)
Non-operating,
power off: < 0.4 G (3 – 100Hz)
Shock Operating: < 2 G (10ms max.)
Non-operating: < 10 G (10ms max.)
Altitude Operating: 0 to 3000m
(above sea level) Non-operating: 0 to 12000m
7
EN
DE
FR
ES
IT
Connections
Power Supply IEC320 3-pin connector, 100 – 240 Vac, 50 – 60 Hz
Analogue I/O
Microphone Balanced, 3-pin XLR-F, Zin = 1kΩ (10kΩ for Hi Z)
Instrument Un-balanced, ¼" Mono Jack, Zin = 1MΩ
Output Balanced, 3-pin XLR-M, Zo = 40Ω
Power 5-pin 180° DIN connector, +5Vdc, ±15Vdc
Specifications
