2. Connect
POWER
+5V - 0.5A
+
/-15V - 0.3A
DC
MANUFACTURED IN U.K.
INPUT
4
3
2
1
OUTPUT
4
3
2
1
Solid State Logic - Oxford - England
ALPHA VHD Pre
Part no. 629998XA
Serial No
12345
Anschlüsse Rückseite
5-pin 180° DIN 3-pin XLR-F 3-pin XLR-M
Pin 1 0V 0V 0V
Pin 2 0V +ve +ve
Pin 3 +5V –ve –ve
Pin 4 –15V
Pin 5 +15V
Anschlüsse Vorderseite
Instrumente Mono Klinke
Spitze Signal
Schirm 0V
Gleichstromeingang
+5V, ±15Vdc aus dem Netzteil
Analogausgang
symmetrisch, max. Ausgangspegel +24dBu
Mikrofoneingänge
Symmetrisch, Max. Input: 0dBu (+20dBu mit Pad)
