6. Operation 6. Operation
.66..65.
6.6.6.3 Meter Set
These settings are used to select the meter types and meter installed locations based
on the actual configuration.
Settings
Meter Set
2015-02-23 19 35
Meter Select
Meter Placement
Y E S = < E N T > N O = < E S C >
Figure 6.36 Meter Set
6.6.6.3.1 Meter Select
Settings
Meter Select
2015-02-23 19 35
Figure 6.37 Meter Select
1Ph Meter
Meter Type:
Y E S = < E N T > N O = < E S C >
E S C
U P
D O W N E N T
“1ph meter”
Meter Type Options
“Acrel 3ph meter”
“Eastron 1ph meter”
“Eastron 1ph meter”
“Eastron 3ph meter”
“Eastron 3ph meter”
“No Meter”
Acrel 1ph meter (With CT): ACR10R-D16TE (Optional)
Meter Model
Acrel 3ph meter (With CT): ACR10R-D16TE4 (Optional)
Eastron 1ph meter (Direct Insert): SDM120M (Optional)
Eastron 1ph meter (With CT): SDM120CT
Eastron 3ph meter (Direct Insert): SDM630 (Optional)
Eastron 3ph meter (With CT): SDM630MCT (Optional)
No meter is connected
Settings
Lead Acid Battery
2015-02-23 19 35
Hot
Environment Temp:
Y E S = < E N T > N O = < E S C >
E S C
U P
D O W N E N T
WARNING:
Lead-acid battery is not recommended for general customers as it requires
experienced installers and technicians who can fully understand the battery
parameters and configure the settings and installations correctly.
Due to the inconformity between battery cells, damages will be less likely
to be avoided. Solis is not responsible for any potential damages caused
by the use of lead-acid batteries.
E S C
U P
D O W N E N T
To Next Page
