OPERATING FEATURES:
Nozzles - Your Solo sprayer is standard with nozzle arrangements which provide a variety of spray patterns.
3
Spray tips should be assembled as follows for desired spray patterns.
SPRAY TIP ASSEMBLY
1. Flat spray nozzle 5. Nozzle cap
2. Filter 6. Nozzle body
3. Jet cap 7. Brass adj. nozzle*
4. Swirl plate 8. Nozzle retaining nut
*Brass adjustable nozzle is not a standard item on all Solo sprayers.
WILL THE PLASTIC MATERIAL LAST?
Only high-grade polyethylene is used. The material is
chosen for high molecular weight, high-impact strength,
and excellent resistance to chemicals and stress.
Ultraviolet inhibitors are used in the material to reduce
deterioration caused by sunlight.
HOW HEAVY IS THE UNIT?
Compression sprayers weigh approximately 5 1/2 lbs.
CAN I USE WEED KILLER AND INSECTICIDE IN
THE SAME SPRAYER?
In theory you can, if the sprayer is thoroughly cleaned
out with a bleach water solution of 1:25. In practice, the
use of both types of chemicals in the same unit is not
recommended as the risk to plants can be high. Use
caution when handling any type of chemicals and when
cleaning your sprayer. Do not mix cleaning agents.
WHAT SPRAY NOZZLE SHOULD I USE?
A flat spray nozzle is supplied for spraying paths, garden
beds, and general area spraying. A cone nozzle is also
supplied for spot spraying and for the treatment of bushes
and small trees. For spot spraying, simply remove swirl plate
from behind nozzle tip. Save the swirl plate for future use.
Available as an option is a reflux filter with a built-in check
valve (27 00 316) which opens at 5 psi and closes at 4 psi.
This virtually eliminates the dripping of fluid still contained
in the spray wand. A wide selection of nozzles such as
deflector, adjustable, and anti-drift nozzles are available.
CAN I DO SPOT SPRAYING?
The shut-off valve on the Solo sprayer is well suited for
spot spraying. It’s almost effortless! The shut-off valve
handle incorporates a clip which holds the valve open for
area spraying without tiring the operator’s hand. A pressure
gauge may be added with increments from 0 to 6 Bar
(0-90 psi).
In the best interest of continued technological progress, we reserve the right to change design and configuration of any product without prior or other notice.
Therefore, please note that text and illustrations of this manual are not to be considered binding and do not constitute a basis for legal or other claims.
Flat spray nozzle Row treatment 4074263
Item Application Part #
Jet stream nozzle Shrubs and bushes 4074755
and swirl plate =
hollow cone
Jet stream nozzle Spot & longer range 4074755 Plastic adjustable Spot, shrubs & bushes
4900527
Item Application Part #
Flat spray Hollow
cone spray
Brass
adjustable
nozzle*
Jet stream Plastic
adjustable
nozzle
No-drip-check valve
replaces # 2 on heavy-duty
models
