SFD-1 TECHNICAL SPECIFICATIONS
Input Receiver UltraAnalog AES20 AES/EBU
ultra-low jitter Input Receiver
Digital Filter NPC 5803 (8-times oversampling)
D/A Converter UltraAnalog D20400A (1 Dual)
Low Pass Proprietary passive configuration
Analog Filter
Frequency Response 5 Hz to 20 kHz ± 0.2 dB
Intrinsic Jitter < 40 ps (picoseconds)
Jitter Rejection From 1 kHz and above (6 dB/octave)
“A” weighted 105 dB (Balanced)
S/N Ratio
Crosstalk > 105 dB @ 1 kHz
> 95 dB 20Hz to 20 kHz
THD + Noise
< 0.02% @ 1kHz
< 0.30% 20Hz to 20kHz
( b a l a n c e d / s i n g l e - e n d e d )
Output Voltage Approx. 2.2 Volts (single-ended)
Approx. 4.4 Volts (balanced)
Output Stage Fully balanced (for AC and DC
parameters), high speed tube buffer
Digital Inputs Coaxial (RCA), Optical (H-P ST-Type
glass), Optical (Toslink)
Analog Outputs 1 pr. Single-ended RCA
1 pr. Balanced XLR
Tube Complement 2 - 6922 (E88CC)
Dimensions 19” Wide x 11” Deep x 4” High
(48 cm x 28 cm x 10 cm)
Weight 19.8 lbs (9 kg) - unpacked
Warranty 5 years parts and labor
1 year on the tubes
This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute
a risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompany-
ing the appliance.
