SFD-2 TECHNICAL SPECIFICATIONS
Input Receiver UltraAnalog AES20 AES/EBU
ultra-low jitter Input Receiver
Digital Filter NPC 5803 (8-times oversampling)
D/A Converters 2 dual UltraAnalog D20400A
(balanced configuration)
Low Pass Proprietary passive configuration
Analog Filter
Frequency Response 5 Hz to 20 kHz + 0.5 dB
20 kHz - 0.1 dB
Intrinsic Jitter < 40 ps (picoseconds)
Jitter Rejection From 1 kHz and above, attenuation rate
6 dB per octave.
“A” weighted > 110 dB
S/N Ratio
Crosstalk > 105 dB @ 1 kHz
> 85 dB @ 10 kHz
THD < 0.05 %
Output Voltage Approx. 3.5 Volts (single-ended)
Approx. 7.0 Volts (balanced)
Output Stage Fully balanced (for AC and DC
parameters), high speed tube buffer
Digital Inputs Coaxial (RCA), Optical (AT&T/ST-Type
glass fibre), AES/EBU (XLR)
Digital Output Coaxial (RCA), 75 ohms
Analog Outputs 1 pr. Single-ended RCA
1 pr. Balanced XLR
Tube Complement 2 - 6922 (E88CC)
Dimensions 19” Wide x 13” Deep x 4” High
Weight 12 kg (26.5 lbs) - unpacked
Warranty 5 years parts and labor
1 year on the tubes
This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute
a risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompany-
ing the appliance.
