Sonim XP3plus Quick Start Guide

/06
How to insert
a new SIM card
Step 1
Use the included screwdriver to unfasten the
battery door screw on the back of the phone.
Step 2
Remove battery door and battery.
Step 3
Slide the SIM door to the left and open the SIM
card tray, insert the SIM card. Close the SIM door
by sliding the door to the right until you hear a click
to lock it in place.
How to insert the battery
Step 1
Insert the battery flush into the cavity such that
the four metallic contacts at the top of the battery
are aligned with the metallic contacts within the
battery compartment.
/07
Step 2
Close the battery cover by turning the screw
in a clockwise direction using the screwdriver
provided. Please ensure you do not over-tighten
the screw.
Initial Phone Set-up
Insert the SIM card into your device. Then, insert
the battery and screw the battery cover closed.
Fully charge your battery (for about 2 hours). Once
fully charged, press and hold Power On / Off key
to turn power On. After the phone successfully
registers with the network, the name of the service
provider is displayed in the Navigation Bar.
When powering the phone On for the first time,
follow the instructions shown on the screen.
After the initial set-up is complete, the Home
Screen is displayed.
Make a call
Use the keypad or select a Contact.
Select the Phone button to enable call.
Set-up Wi-Fi
From Home Screen, select App tray:
Settings > Wi-Fi > On > choose network >
enter password > Connect

Sonim XP3plus Specifications

General

Display Size	2.8 inches
Resolution	240 x 320 pixels
Battery Capacity	2300 mAh
Rear Camera	5 MP
Status	Available
Network	GSM / HSPA / LTE
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
Speed	HSPA, LTE
MIL-STD-810H compliant	Yes
Type	TFT
CPU	Quad-core 1.3 GHz Cortex-A53
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	4.2, A2DP
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
Radio	FM radio
USB	USB Type-C 2.0
Sensors	Accelerometer, proximity
Colors	Black
SIM	Dual SIM
IP rating	IP68 dust/water resistant (up to 1.5m for 30 min)
WLAN	Wi-Fi 802.11 a/b/g/n/ac
4G bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 20, 25, 26, 28, 38, 39, 40, 41
