Sonos Port User Manual

If you don’t have the app, download it from the app store on your mobile device. You’ll use it to set up and
control your Sonos system.
Line-in
Connect an external source like a phono preamp (your turntable may have a built-in phone preamp), or other
audio device. Learn more.
Line-out
Control volume from your AVR or amplifier (Fixed line-out level)
Set Port’s line-out level to Fixed if you want to control the volume exclusively from your AVR or amplifier. You
won’t be able to use the Sonos app to adjust the volume or equalization settings.
Go to settings and choose Fixed for the Line-Out Level.
Control the volume from Sonos (Variable line-out level)
When Port’s line-out level is set to Variable, you can use the Sonos app to adjust the volume.
1. Adjust your AVR or amplifier’s volume to your typical listening volume.
2. Make sure the line-out level is set to Variable. If it’s not, you’ll need to change it:
Go to settings and choose Variable for the Line-Out Level.
3. Use the Sonos app to adjust the volume so you can hear music on your Sonos system. It may need to
be turned up fairly high.
4. Readjust the volume on your AVR or amplifier so it falls within your typical listening range.
Use Sonos to control the volume on your home theater or amplifier
When Port’s line-out level is set to Pass-Through, Port stays at a fixed volume and sends volume commands
to your amplifier. You can control volume using the Sonos app, a universal remote, or your voice if you have a
voice assistant enabled.
Go to settings and choose Pass-Through for the Line-Out Level.
Note: Make sure your amplifier supports Pass-Through. If you set the line-out level to Pass-Through and your
amplifier doesn’t support it, you won’t be able to control the volume.
Specifications
Feature Description
Audio
Sound Quality THD+N<0.009%, 20 Hz-20 kHz
Line In Analog (RCA), auto-detecting
Line Out Analog (RCA), digital (coaxial)
Networking*
Wireless Connectivity Connects to your home WiFi network with any 802.11b/g/n router.
802.11n only network configurations are not supported—you can
either change the router settings to 802.11b/g/n or connect a Sonos
product to your router.
Ethernet port Two 10/100 Mbps Ethernet ports to connect to a wired home
network.
General

Sonos Port Specifications

General

AirPlay	Yes
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g
Ethernet LAN data rates	10, 100 Mbit/s
Apple docking compatibility	Not supported
Product color	Black
AC input voltage	100-240 V
AC input frequency	50-60 Hz
Cables included	AC, RCA
Built-in processor	-
Mobile operating systems supported	iOS 11.4
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Total Harmonic Distortion (THD)	0.009 %

Weight and Dimensions

Width	138 mm
Height	41 mm
Weight	472 g
