ARRANGE PARTS INTO GROUPS AS LISTEN IN YOUR PACK CONTENTS
UNFOLD COVER AND PUT TO ONE SIDE
STEP 1 Parts:
4 x D 8 x E 8 x K 4 x F 6 x M 2 x I 12 x L
Assemble the base with the above parts. Once base is assembled build
upwards using the parts listed in step 2.
STEP 2 Parts:
8 x E 4 x B 6 x M 4 x F 12 x L 8 x K
This forms the next level. Once complete build the next level with parts
listed in step 3.
STEP 3 Parts:
2 x B 2 x D 8 x E 8 x K 6 x M 8 x L 4 x F
This forms the next level. Once completed build the next level with parts
listed in step 4.
STEP 4 Parts:
4 x A 2 x C 2 x E 1 x I 2 x M 4 x K 6 x N
This forms the next level. Once completed build the next level with parts
listed in step 5.
STEP 5 Parts:
2 x J 1 x H 1 x G 2 x K
This forms the final level. Once completed place the cover over the
frame and attach.
Serial No.
A
J
D
E
B
C
H
Picture QTY
4
2
6
26
6
2
1
Serial No.
I
K
L
M
N
F
G
Clear Cover
QTY
3
30
32
20
6
12
1
PACK CONTENT
30 in.
26 in.
15 in.
11 in.
39.5 in.
Please check contents before attempting to construct
