LFO mode
In LFO mode, an internal low-frequency-oscillator ( LFO ) controls the filter cutoff. The speed of the LFO
can be controlled precisely and can even be synchronised with a sequencer using MIDI ( “ MIDI operation”
on page 25
). The following sub-parameters configure the LFO .
LFO sub-
parameter
Range Description
tyP
tPo
-F1
tAP
PEd
Syn
Type of LFO clock:
tempo in bpm
derived from filter 1’s
LFO (only available for filter 2)
pedal is used to tap a tempo
pedal controls max (bP.h) and min (bP.L) bpm
sync’d to
MIDI clock
bPM 10–999 Sets LFO tempo in bpm. Only available if tyP is set to tPo.
bP.h 10–999
bpm high: bpm when footpedal is in toe down position.
Only available when tyP is set to PEd. bpm is interpolated
between bpm-high and bpm-low depending on the
position of the footpedal.
bP.L 10–999
bpm low: bpm when footpedal is in heel down position.
Only available when tyP is set to PEd.
div
16, 8, 6, 4, 3, 2, 1,
1
/
2
,
1
/
4
,
1
/
8
,
1
/
16
Clock multiplier. For example, if the clock is 120bpm and
div is set to
1
/
2
, the LFO clock will run at 60bpm.
ShP
Sin
tri
Sqr
S.uP
S.dn
trP
rnd
Shape of LFO waveform:
sinusoid
triangle
square
saw up
saw down
trapezoid
random
StE oFF, 1–16 Step: quantizes the LFO output to this number of steps.
r.uP 0–100
Ramp up: only available for trapezoid. See below for details
on how trapezoids are set up.
r.dn 0–100 Ramp down: only available for trapezoid.
PhA 0–63
Phase: controls the phase of filter 2 relative to filter 1. Only
available when tyP is -F1,
i.e., filter 2 is sync’d to filter 1.
