Rear side
Eyepiece cup
To remove the eyepiece cup
Push the grips at the bottom
of the eyepiece cup to the left
and right and lift up the cup.
Viewfinder
C3 button (Custom
button3)/(Protect) button
MENU button (15)
Monitor
(For touch operation: Touch
panel/Touch pad) (38)
You can adjust the monitor to
an easily viewable angle and
shoot from any position.
Eye sensor
To Next Page
