Sony CDX-GT71W Service Manual

53
CDX-GT71W/GT710/GT760
C425 1-124-717-85 ELECT 1uF 20% 50V
(AEP,UK)
C425 1-126-960-11 ELECT 1uF 20% 50V
(EXCEPT AEP,UK)
C426 1-124-717-85 ELECT 1uF 20% 50V
(AEP,UK)
C426 1-126-960-11 ELECT 1uF 20% 50V
(EXCEPT AEP,UK)
C427 1-126-960-11 ELECT 1uF 20% 50V
C428 1-126-960-11 ELECT 1uF 20% 50V
C429 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C430 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C433 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C434 1-124-673-85 ELECT 100uF 20% 10V
(AEP,UK)
C434 1-126-933-11 ELECT 100uF 20% 16V
(EXCEPT AEP,UK)
C442 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C443 1-126-964-11 ELECT 10uF 20% 50V
C455 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C501 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C502 1-126-964-11 ELECT 10uF 20% 50V
C503 1-126-963-11 ELECT 4.7uF 20% 50V
(AEP,UK)
C505 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C509 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C510 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C512 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C513 1-126-933-11 ELECT 100uF 20% 16V
C514 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT AEP,UK)
C544 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C551 1-126-947-11 ELECT 47uF 20% 35V
(AEP,UK)
C552 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(AEP,UK)
C553 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP,UK)
C554 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP,UK)
C555 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP,UK)
C556 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP,UK)
C557 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP,UK)
C558 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP,UK)
C559 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
(AEP,UK)
C560 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
(AEP,UK)
C561 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
(AEP,UK)
C620 1-125-972-61 ELECT 100uF 20% 16V
C621 1-128-552-11 ELECT 47uF 20% 63V
C622 1-125-972-61 ELECT 100uF 20% 16V
C623 1-126-096-11 ELECT 10uF 20% 35V
C624 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C625 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C626 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C628 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C629 1-126-933-11 ELECT 100uF 20% 16V
C630 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C632 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C701 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C703 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C704 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C705 1-126-947-11 ELECT 47uF 20% 35V
C706 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C707 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C708 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C709 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
* CN401 1-564-506-11 PLUG, CONNECTOR 3P
CN604 1-785-900-21 CONNECTOR 5P
CN605 1-785-900-21 CONNECTOR 5P
* CN702 1-566-762-11 PIN, CONNECTOR (PC BOARD) 7P
CN801 1-818-076-71 CONNECTOR, FFC/FPC (ZIF) 36P
< JACK >
CNJ101 1-566-822-41 JACK (REMOTE IN)
< CONNECTOR >
CNP101 1-774-701-21 PIN, CONNECTOR 16P
CNP102 1-580-907-41 PLUG, CONNECTOR 8P (BUS CONTROL IN)
CNP301 1-820-611-11 CONNECTOR, BOARD TO BOARD 28P
< DIODE >
D101 8-719-057-80 DIODE MA8180-M-TX
D102 8-719-057-80 DIODE MA8180-M-TX
D103 8-719-058-24 DIODE RB501V-40TE-17
D104 8-719-422-64 DIODE MA8062-M
D105 8-719-057-80 DIODE MA8180-M-TX
D106 8-719-977-12 DIODE DTZ6.8B
D108 8-719-057-80 DIODE MA8180-M-TX
D109 6-501-571-01 DIODE 1N5404-C311-3
D110 8-719-053-18 DIODE 1SR154-400TE-25
D111 8-719-053-18 DIODE 1SR154-400TE-25
D112 8-719-053-18 DIODE 1SR154-400TE-25
D113 8-719-053-18 DIODE 1SR154-400TE-25
D114 8-719-053-18 DIODE 1SR154-400TE-25
D115 8-719-053-18 DIODE 1SR154-400TE-25
D116 8-719-053-18 DIODE 1SR154-400TE-25
D117 8-719-053-18 DIODE 1SR154-400TE-25
D118 8-719-053-18 DIODE 1SR154-400TE-25
D119 8-719-053-18 DIODE 1SR154-400TE-25
D120 8-719-053-18 DIODE 1SR154-400TE-25
D121 8-719-053-18 DIODE 1SR154-400TE-25
D125 6-501-193-01 DIODE 1SS355WTE-17
D128 6-501-654-01 DIODE LBAT54CLT1G
D138 8-719-057-80 DIODE MA8180-M-TX
D139 8-719-057-80 DIODE MA8180-M-TX
D301 6-501-656-01 DIODE LBAT54ALT1G
D303 6-501-193-01 DIODE 1SS355WTE-17
D304 6-501-193-01 DIODE 1SS355WTE-17
D401 6-501-193-01 DIODE 1SS355WTE-17
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
