Using the display
You can check information about the CD using the
display.
Checking the information of an audio CD
To check the total track number and playing
time of the CD
Press
on the unit twice, and you can check them
in the display.
Total track number
Total playing time
Checking the information of an MP3 disc
To check the total folder number and total file
number on the CD
Press
on the unit twice, and you can check them
in the display.
Total file
number
Total folder
number
To check file information
Press DISPLAY/ENTER
on the unit while playing an
MP3 disc. The display changes as follows:
The current file number and playing time
The song title
The artist name
The album name*
If the file does not have ID3 tag information, “NO TITLE”, “NO
ARTIST” and “NO ALBUM” appear in the display.
* If there is no folder, “ROOT” appears.
Playing tracks/MP3 files repeatedly
(Repeat Play)
You can play tracks/MP3 files repeatedly in normal and
program play modes.
1 Press OPERATE (or POWER)
.
2 Press CD
on the unit.
(On the remote, press FUNCTION
repeatedly
until “CD” appears in the display.)
3 Proceed as follows.
To repeat Do this
A single
track/MP3
file
1 Press MODE
(press , then
press MODE during playback) on
the unit until “ 1” appears.
2 Press
or
to select the
track/MP3 file that you want to repeat.
3 Press
.
All tracks/
MP3 files
on the CD
1 Press MODE
(press , then
press MODE during playback) on
the unit until “ ” appears.
2 Press
.
A selected
folder (MP3
disc only)
1 Press MODE
(press , then
press MODE during playback)
on the unit until “FOLDER” and “ ”
appear.
2 Select the folder by pressing
+ or –
on the unit.
3 Press
.
Programed
tracks/MP3
files
1 Program tracks/MP3 files (see “Creating
your own program”).
2 Press MODE
(press , then
press MODE during playback) on
the unit until “PGM” and “ ” appear.
3 Press
.
To cancel Repeat Play
Press MODE (press , then press MODE
during playback) on the unit until “ ” disappears from
the display.
Other Operations
Playing tracks/MP3 files in random
order (Shuffle Play)
You can play tracks/MP3 files in random order.
1 Press OPERATE (or POWER)
.
2 Press CD
on the unit.
(On the remote, press FUNCTION
repeatedly
until “CD” appears in the display.)
3 Press MODE
(press
, then press MODE
during playback) on the unit until “SHUF” appears in
the display.
4 Press
to start Shuffle Play.
To cancel Shuffle Play
Stop playing first. Then press MODE
(press
,
then press MODE
during playback) on the unit until
“SHUF” disappears from the display.
Tips
During Shuffle Play, you cannot select the previous track/MP3 file
by pressing
.
The resume function does not work during Shuffle Play.
Creating your own program (Program
Play)
You can arrange the playing order of up to 20 tracks/
MP3 files on a CD.
1 Press OPERATE (or POWER)
.
2 Press CD
on the unit.
(On the remote, press FUNCTION
repeatedly
until “CD” appears in the display.)
3 Press MODE (press , then press MODE
during playback) on the unit until “PGM” appears in
the display.
4 Press
or
then press DISPLAY/ENTER
on the unit for the tracks you want to program in
the order you want.
For MP3 files, press + or – first and then press
or
and DISPLAY/ENTER on the unit.
Audio CD
Programed track
number
Playing order
MP3 disc
Programed file
number
Playing order
5 Press
to start Program Play.
To cancel Program Play
Stop playing first. Then press MODE
on the unit
until “PGM” disappears from the display.
To check the order of tracks/MP3 files
Press DISPLAY/ENTER
(press
, then press
DISPLAY/ENTER
during playback) on the unit.
Every time you press the button, the track/MP3 file
number appears in the programed order.
To change the current program
Press
once if the CD is stopped and twice if the
CD is playing. The current program will be erased. Then
create a new program following the programming
procedure.
Tips
If you try to program 21 tracks/MP3 files or more, “FULL” will
appear in the display.
You can play the same program again, since the program is saved
until you open the CD compartment or turn off the unit.
You can record your own program. After you have created the
program, insert a blank tape and press
on the unit to start
recording.
The resume function does not work during Program Play.
Presetting radio stations
You can store radio stations into the unit’s memory.
You can preset up to 30 radio stations, 20 for FM and
10 for AM in any order.
1 Press OPERATE (or POWER)
.
2 Press RADIO BAND
on the unit (BAND
on the
remote) to select the band.
3 Hold down AUTO PRESET
on the unit for
2 seconds until “AUTO” flashes in the display.
4 Press DISPLAY/ENTER
on the unit.
The stations are stored in memory from the lower
frequencies to the higher ones.
If a station cannot be preset automatically
You need to preset a station with a weak signal
manually.
1 Press OPERATE (or POWER)
.
2 Press RADIO BAND
on the unit (BAND
on the
remote) to select the band.
3 Tune in a station you want using TUNE + or –
on
the unit.
4 Hold down MEMORY
on the unit for 2 seconds
until the preset number flashes in the display.
5 Press PRESET + or –
until the preset number you
want for the station flashes in the display.
6 Press DISPLAY/ENTER
on the unit.
The new station replaces the old one.
Tip
The preset radio stations remain in memory even if you unplug the
AC power cord or remove the batteries.
Playing preset radio stations
1 Press OPERATE (or POWER)
.
2 Press RADIO BAND
on the unit (BAND
on the
remote) to select the band.
3 Press PRESET + or –
to tune in the stored station.
Connecting optional components
You can enjoy the sound from an optional component
such as a portable digital music player through the
speakers of this unit. Be sure to turn off the power
of each component before making any connections.
For details, refer to the instruction manual of the
component to be connected.
1 Connect the AUDIO IN jack
to the line output
jack of the portable digital music player or other
components using an audio connecting cable (not
supplied).
2 Press OPERATE (or POWER)
to turn the unit on.
3 Turn the connected component on.
4 Press AUDIO IN
on the unit (on the remote, press
FUNCTION
repeatedly until “AUDIO IN” appears
in the display), and start playback on the connected
component.
The sound from the connected component is
output from the speakers of this unit.
To connect the unit to a TV or VCR, use an extension
cable (not supplied) with a stereo-mini jack on one
end and two phono plugs on the other end.
Tip
You can record the sound of the connected component. Insert a
blank tape and press on the unit.
Precautions
Discs that this unit CAN play
• Audio CD
• CD-R/CD-RW (CD-DA*/MP3 files)
* CD-DA is the abbreviation for Compact Disc Digital Audio. It is a
recording standard used for Audio CDs.
Discs that this unit CANNOT play
• CD-R/CD-RW other than those recorded in music CD
format or MP3 format conforming to ISO9660 Level
1/Level 2 or Joliet
•
CD-R/CD-RW of poor recording quality, CD-R/CD-RW
that has scratches or are dirty, or CD-R/CD-RW
recorded with an incompatible recording device
•
CD-R/CD-RW which is finalized incorrectly
Notes on discs
• Before playing, clean the CD
with a cleaning cloth. Wipe the
CD from the center out. If there
is a scratch, dirt or fingerprints
on the CD, it may cause tracking
error.
• Do not use solvents such as benzine, thinner,
commercially available cleaners or anti-static spray
intended for vinyl LPs.
• Do not expose the CD to direct sunlight or heat
sources such as hot air ducts, nor leave it in a
car parked in direct sunlight as there can be a
considerable rise in temperature inside the car.
• Do not stick paper or sticker on the CD, nor scratch
the surface of the CD.
• After playing, store the CD in its case.
On safety
• As the laser beam used in the CD player section is
harmful to the eyes, do not attempt to disassemble
the casing. Refer servicing to qualified personnel
only.
• Should any solid object or liquid fall into the unit,
unplug the unit, and have it checked by qualified
personnel before operating it any further.
• Discs with non-standard shapes (e.g., heart, square,
star) cannot be played on this unit. Attempting to do
so may damage the unit. Do not use such discs.
On power sources
• For AC operation, check that the unit’s operating
voltage is identical with your local power supply (see
“Specifications”) and use the supplied AC power cord;
do not use any other type.
• Unplug the unit from the wall outlet when it is not be
used for an extended period of time.
• When the batteries are not to be used, remove them
to avoid damage that can be caused by battery
leakage or corrosion.
On placement
• Do not leave the unit in a location near heat sources,
in a place subject to direct sunlight, excessive dust or
mechanical shock or in a car subject to the direct rays
of the sun.
• Do not place the unit on an inclined or unstable
place.
• Do not place anything within 10 mm of the side
of the cabinet. The ventilation holes must be
unobstructed for the unit to operate properly and
prolong the life of its components.
• Since a strong magnet is used for the speakers, keep
personal credit cards using magnetic coding or
spring-wound watches away from the unit to prevent
possible damage from the magnet.
On operation
• If the unit is brought directly from a cold to a warm
location, or is placed in a very damp room, moisture
may condense on the lens inside the CD player
section. Should this occur, the unit will not operate
properly. In this case, remove the CD and wait about
an hour for the moisture to evaporate.
• If the unit has not been used for a long time, set it in
the playback mode to warm it up for a few minutes
before inserting a cassette.
Notes on cassettes
• Break off the cassette
tab from side A or B
to prevent accidental
recording. If you want
to reuse the tape for
recording, cover the
broken tab with adhesive
tape.
Side A
Tab for side A
Tab for side B
• The use of a cassette with more than 90 minutes
of play time is not recommended except for long,
continuous recording or playback.
Cleaning the cabinet
• Clean the cabinet, panel and controls with a soft cloth
slightly moistened with a mild detergent solution. Do
not use any type of abrasive pad, scouring powder, or
solvent, such as alcohol or benzine.
If you have any questions or problems concerning your
unit, please consult your nearest Sony dealer.
General
The power is not on.
Connect the AC power cord to the wall outlet
securely.
Make sure the batteries are inserted correctly.
Replace all the batteries with new ones if they are
weak.
You cannot turn on the unit with the remote when
you operate the unit on batteries.
There is no audio.
Unplug the headphones when listening through
speakers.
Noise is heard.
Someone is using a portable telephone or other
equipment that emits radio waves near the unit.
Move the portable telephone, etc., away from the
unit.
CD/MP3 player
The CD does not play or “NO DISC” is displayed
even when a CD is in place.
Place the CD with the label surface up.
Clean the CD.
Take out the CD and leave the CD compartment open
for about an hour to dry moisture condensation.
The CD-R/CD-RW is blank.
There is a problem with the quality of the CD-R/
CD-RW, recording device or application software.
Replace all the batteries with new ones if they are
weak.
The sound drops out.
Reduce the volume.
Clean the CD, or replace it if the CD is badly damaged.
Place the unit in a location free from vibration.
Clean the lens with a commercially available blower.
The sound may drop out or noise may be heard
when using a poor quality CD-R/CD-RW or if there is
a problem with the recording device or application
software.
Starting playback takes more time than usual.
The following discs take a longer time to start
playback.
– a disc recorded with a complicated tree structure.
– a disc that has not been finalized (a disc to which
data can be added).
– a disc that has many folders or non-MP3 files.
Radio
Reception is poor.
Reorient the
antenna to
improve FM
reception.
Reorient the unit
itself to improve
AM reception.
The audio is weak or has poor quality.
Replace all the batteries with new ones if they are
weak.
Move the unit away from the TV.
If you are using the remote while listening to AM
radio, noise may be heard.
The picture of your TV becomes unstable.
If you are listening to an FM program near the TV
with an indoor antenna, move the unit away from the
TV.
Tape player
The tape does not move when you press an
operation button.
Close the cassette compartment securely.
The button
does not function or the tape
does not play or record.
Make sure the safety tab on the cassette is in place.
Poor or distorted playback, recording or
erasing quality.
Clean the heads by using dry- or wet-type cleaning
cassette (available separately) after every 10 hours of
use, before you start an important recording, or after
playing an old tape. Failure to clean the tape heads
can cause degraded sound quality or an inability of
the unit to record or play tapes. For details, refer to
the instructions of the cleaning cassette.
The TYPE II (high position) or TYPE IV (metal) tape is
being used. Use TYPE I (normal) tape only.
Demagnetize the heads using a commercially
available tape head demagnetizer.
Replace all the batteries with new ones if they are
weak.
Remote
The remote does not function.
Replace all the batteries in the remote with new ones
if they are weak.
Make sure that you are pointing the remote at the
remote sensor on the unit.
Remove any obstacles in the path of the remote and
the unit.
Make sure the remote sensor is not exposed to strong
light such as direct sunlight or fluorescent lamp light.
Move closer to the unit when using the remote.
After trying the remedies, if you still have problems,
unplug the AC power cord or remove all the batteries.
After all the indications in the display disappear, plug
the AC power cord or insert the batteries again. If the
problem persists, please consult your nearest Sony
dealer.
Troubleshooting
To Previous Page
Loading...
Need help?
General
Weight and Dimensions
