21
D-EJ360/EJ368CK
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C626 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C627 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C629 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C631 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C632 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C633 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
C801 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C802 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C803 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C804 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C805 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C806 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C807 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C808 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C809 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C810 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C811 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EJ360)
C811 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
(EJ368CK)
C812 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C813 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C814 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN401 1-784-342-21 HOUSING, CONNECTOR 2P
* CN402 1-785-877-21 HOUSING, CONNECTOR 4P
* CN601 1-816-237-21 CONNECTOR, FFC/FPC (ZIF) 15P
< DIODE >
D101 8-719-420-87 DIODE MA8130
D201 8-719-420-87 DIODE MA8130
D301 8-719-420-87 DIODE MA8130 (EJ368CK)
D302 8-719-420-87 DIODE MA8130 (EJ368CK)
D306 8-719-420-87 DIODE MA8130 (EJ368CK)
D308 8-719-059-53 DIODE MA3J14700LSO
D402 8-719-067-42 DIODE MA2H735-(TX).SO
D403 8-719-067-42 DIODE MA2H735-(TX).SO
D404 8-719-404-50 DIODE MA111-TX
D405 8-719-067-42 DIODE MA2H735-(TX).SO
D406 8-719-069-54 DIODE UDZSTE-175.1B
D409 8-719-404-50 DIODE MA111-TX
D410 8-719-067-42 DIODE MA2H735-(TX).SO
D802 8-719-072-70 DIODE MA2ZD14001S0
< FERRITE BEAD >
FB101 1-500-234-22 FERRITE 0uH
FB201 1-500-234-22 FERRITE 0uH
FB301 1-469-152-11 FERRITE 0uH (EJ368CK)
FB302 1-469-152-11 FERRITE 0uH (EJ368CK)
FB303 1-500-234-22 FERRITE 0uH
FB401 1-216-864-11 METAL CHIP 0 5% 1/10W
FB402 1-216-864-11 METAL CHIP 0 5% 1/10W
FB403 1-216-864-11 METAL CHIP 0 5% 1/10W
FB404 1-216-864-11 METAL CHIP 0 5% 1/10W
FB405 1-216-864-11 METAL CHIP 0 5% 1/10W
FB406 1-216-864-11 METAL CHIP 0 5% 1/10W
FB408 1-216-864-11 METAL CHIP 0 5% 1/10W
< IC >
IC301 8-759-681-65 IC TA2120FN(EL)
IC403 6-703-034-01 IC BH6580KV
IC601 6-703-033-01 IC BU9354KV
IC602 6-703-609-01 IC MSM51X4400E-10TSK-FS (EXCEPT US)
IC603 6-702-737-01 IC MSM51X17400F-10TFSR1 (US)
IC801 6-802-331-02 IC T5AW5-4N69
< JACK >
J301 1-815-135-32 JACK, HEADPHONE (i) (EJ360)
J301 1-815-088-41 JACK, HEADPHONE (i) (EJ368CK)
J401 1-778-153-21 JACK,DC(POLARITY UNIFIED TYPE)
(DC IN 4.5V)
< COIL >
L401 1-400-373-21 INDUCTOR 4.7uH
L402 1-400-373-21 INDUCTOR 4.7uH
L403 1-400-145-21 INDUCTOR 47uH
L404 1-414-406-41 INDUCTOR 220uH
L406 1-400-145-21 INDUCTOR 47uH
L407 1-419-387-21 INDUCTOR 100uH
L408 1-216-296-11 SHORT CHIP 0
L409 1-400-145-21 INDUCTOR 47uH
L410 1-400-145-21 INDUCTOR 47uH
L411 1-414-402-11 INDUCTOR 47uH
L412 1-216-296-11 SHORT CHIP 0
L601 1-469-967-21 INDUCTOR 10uH
L602 1-216-295-91 SHORT CHIP 0
L603 1-216-295-91 SHORT CHIP 0
L604 1-469-570-21 INDUCTOR 10uH
L605 1-216-295-91 SHORT CHIP 0
< LIQUID CRYSTAL DISPLAY >
LCD801 A-3364-765-A LCD ASSY (EJ360:US,CND/
EJ368CK:AEP,AUS,CND,C&SA,MX)
LCD801 A-3364-797-A LCD ASSY (EJ360:AEP,E,EE/EJ368CK:US)
< TRANSISTOR >
Q401 8-729-921-73 TRANSISTOR 2SD1781K-QR
Q402 6-550-070-01 TRANSISTOR 2SB1237TV2PQR
Q403 8-729-231-74 TRANSISTOR 2SC4116-GL
Q404 8-729-054-79 TRANSISTOR 2SB167900LSO
Q406 8-729-044-84 TRANSISTOR CPH3403-TL-E
Q407 8-729-905-40 TRANSISTOR 2SC4081T106
Q601 8-729-054-79 TRANSISTOR 2SB167900LSO
< RESISTOR >
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EJ360:US,CND,E/EJ368CK)
R102 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EJ360:AEP,EE)
R103 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EJ360:AEP,EE)
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EJ360:US,CND,E/EJ368CK)
R104 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R201 1-216-833-11 METAL CHIP 10K 5% 1/10W
R202 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EJ360:US,CND,E/EJ368CK)
R202 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EJ360:AEP,EE)
R203 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EJ360:AEP,EE)
Ver 1.1 2003.03
