DSC-F717
6-28
19. Auto White Balance 3200K Check 2
RadarWRadarWRadarW
Mode CAMERA
Subject Clear chart
(Standard picture frame with the
zoom lens at WIDE end)
Measurement Point Displayed data of page: F, address:
7C, 7D
Measuring Instrument Adjusting remote commander
Specified Value 1 00 to 2F, EE to FF
Specified Value 2 00 to 23, F6 to FF
Note 1: Perform this check after “Auto white Balance 3200K
Check 1” without a break.
Note 2: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Checking method:
Order Page Address Data Procedure
1
“Auto White Balance 3200K
Check 1” is completed.
2F 7C
Check that the data specified
value 1.
3F 7D
Check that the data specified
value 2.
Processing after Completing Adjustment:
Order Page Address Data Procedure
1
Perform “Auto White
Balance 3200K Check 3”.
20. Auto White Balance 3200K Check 3
RadarW
RadarW
Mode CAMERA
Subject Clear chart
(Standard picture frame with the
zoom lens at WIDE end)
Measurement Point Displayed data of page: F, address:
82, 83
Measuring Instrument Adjusting remote commander
Specified Value 1 00 to 82, E7 to FF
Specified Value 2 00 to 6D, F1 to FF
Note 1: Perform this check after “Auto white Balance 3200K
Check 2” without a break.
Note 2: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Checking method:
Order Page Address Data Procedure
1
“Auto White Balance 3200K
Check 2” is completed.
2F 82
Check that the data specified
value 1.
3F 83
Check that the data specified
value 2.
Processing after Completing Adjustment:
Order Page Address Data Procedure
1 6 37 00
2 0 03 00
3
Release the data setting
performed at step 1 in “Auto
White Balance 3200K
Standard Data Input 1”.
(Refer to page 6-22)
To Next Page
