Sony DSC-R1 Fall 2005 Usage Manual

Usage Guide
Page 4 COSTAR - CONFIDENTIAL/TRADE SECRET
DSC-
R1
Zooming Ring (p. 71)
Twisting the Zooming Ring allows the user to change the focal length of the
camera’s lens system between 24mm to 120mm (135mm equivalent).
Manual Focus Ring (p. 48)
When the camera is engaged in Manual Focus Mode, turning this ring will focus
the camera.
Shutter Button
Depressing the shutter button halfway will engage the cameras autofocus and
exposure systems. Holding the button at halfway will freeze the focus and
exposure settings. Pressing the button completely will snap a photo.
Lens Hood (p. 18)
Using the Lens Hood during bright lighting conditions can reduce image quality
deteriation caused by unnecessary light.
ISO Button (p. 45)
This button, when used with the Main Command Dial, allows the user to chose
a luminous sensitivity with units of ISO.
Advanced Accessory Shoe (p. 52)
The Advanced Accessory Shoe allows the user to attach various add-on
accessories such as an External Flash.
Advanced Accessory Shoe
Shutter Button
Power Switch
ISO Button
Power Lamp
Zooming Ring
Lens Hood
Manual Focus Ring

Sony DSC-R1 Fall 2005 Specifications

General

Sensor Type	CMOS
Sensor Size	APS-C (21.5 x 14.4 mm)
Resolution	10.3 MP
Aperture	f/2.8-4.8
ISO Range	160-3200
Viewfinder	Electronic
Shutter Speed	30 - 1/2000 sec
Lens Mount	Fixed lens
LCD Resolution	134, 000 dots
LCD Screen	2.0"
Storage Type	CompactFlash, Memory Stick
Weight	995 g
Battery	Lithium-Ion
Lens	Carl Zeiss Vario-Sonnar T* 24-120mm (35mm equiv.) f/2.8-4.8
