5-11
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-W80/W85_L3
SY-173
D706 6-501-216-01 DIODE CL-271HR-C-TS (MS ACCESS)
D707 6-500-813-01 DIODE MA2SD32008S0
D708 6-500-813-01 DIODE MA2SD32008S0
D712 6-500-813-01 DIODE MA2SD32008S0
< FUSE >
0 F001 1-576-843-21 FUSE (0.8A/32V)
0 F002 1-576-851-21 FUSE (2A/32V)
< FERRITE BEAD >
FB211 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB212 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB213 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB214 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB215 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB281 1-218-990-81 SHORT CHIP 0 (Note)
FB282 1-469-081-21 INDUCTOR, FERRITE BEAD (1005)
FB283 1-469-081-21 INDUCTOR, FERRITE BEAD (1005)
FB307 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB310 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB311 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB312 1-400-620-21 INDUCTOR, FERRITE BEAD (1005)
FB313 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB701 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB702 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB703 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB704 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB705 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
< IC >
* IC001 6-710-930-01 IC MAX8611VETM+TG069
* IC002 6-709-726-01 IC SN0510064DRCR
* IC003 6-710-847-01 IC TK63718AB1G0B
* IC007 6-710-970-01 IC XC6108C10BGR
IC101 6-807-554-01 IC MB89083LGA-G-133-ERE1
* IC102 6-710-971-01 IC NJU7287ARB1 (TE2)
* IC106 6-711-152-01 IC S-80822CNPF-B8HTFG
* IC201 6-807-231-01 IC uPD79F0043FC-401-2N1-E2-A
* IC202 6-710-976-01 IC ICS620AN-09LFT
IC211 (Not supplied) IC PRX515101B
* IC304 6-709-616-01 IC VSP00M21ZWDR
* IC305 6-710-852-01 IC NJM2831F125 (TE1)
* IC306 6-710-849-01 IC TK63733AB1G0B
* IC308 6-710-845-01 IC TK70628HCL-G
IC401 6-708-988-01 IC LV8053LG-TLM-E
* IC501 6-710-813-01 IC TK63728AB1G0B
* IC502 6-709-769-01 IC TK63715AB1G0B
* IC503 6-709-026-01 IC R2J30500LG
IC506 8-753-276-73 IC CXA3739ER-T2
* IC601 6-710-813-01 IC TK63728AB1G0B
IC602 6-707-834-01 IC BH76812FVM-STR
IC603 6-707-336-01 IC BH6414GLU-SE2
< COIL >
L001 1-400-676-11 INDUCTOR 22uH
L002 1-457-066-21 INDUCTOR 4.7uH
L003 1-457-066-21 INDUCTOR 4.7uH
L004 1-457-066-21 INDUCTOR 4.7uH
• Refer to page 5-1 for mark 0.
L005 1-457-066-21 INDUCTOR 4.7uH
L006 1-457-066-21 INDUCTOR 4.7uH
* L007 1-457-436-21 COIL, CHOKE 2.4uH
L008 1-457-066-21 INDUCTOR 4.7uH
L009 1-457-066-21 INDUCTOR 4.7uH
L101 1-216-295-91 SHORT CHIP 0 (Note)
L201 1-412-983-31 INDUCTOR 2.2uH
L211 1-400-137-11 INDUCTOR 10uH
L241 1-469-570-11 INDUCTOR 10uH
L242 1-400-137-11 INDUCTOR 10uH
L301 1-400-678-11 INDUCTOR 100uH
L302 1-400-678-11 INDUCTOR 100uH
L701 1-400-137-11 INDUCTOR 10uH
< LINE FILTER >
LF701 1-456-583-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
Q003 6-550-576-01 TRANSISTOR SSM6E01TU
Q004 8-729-047-68 TRANSISTOR SSM3K03FE (TPL3)
Q006 8-729-055-32 TRANSISTOR 3LN01SS-TL
Q007 6-550-674-01 TRANSISTOR MCH6604-K-TL-E
Q010 6-551-674-01 TRANSISTOR SCH1302-TL-E
Q012 6-550-236-01 TRANSISTOR UNR32A000LS0
Q013 6-550-844-01 TRANSISTOR FDW2508P/GNL
Q014 6-550-576-01 TRANSISTOR SSM6E01TU
Q101 8-729-054-52 TRANSISTOR UP04216008S0
Q241 6-551-674-01 TRANSISTOR SCH1302-TL-E
Q242 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q243 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q244 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q301 6-550-119-01 TRANSISTOR DTC144EMT2L
Q302 8-729-054-47 TRANSISTOR UP04213008S0
Q303 6-550-791-01 TRANSISTOR SSM3J15FV (TL3SONYZ)
Q305 6-550-674-01 TRANSISTOR MCH6604-K-TL-E
* Q401 6-551-224-01 TRANSISTOR RN2110ACT (TL3SONY)
Q704 8-729-053-52 TRANSISTOR HN1C01FE-Y/GR (TPLR3)
Q706 6-550-576-01 TRANSISTOR SSM6E01TU
Q710 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
< RESISTOR >
R002 1-218-985-11 RES-CHIP 470K 5% 1/16W
R003 1-218-989-11 RES-CHIP 1M 5% 1/16W
R005 1-218-973-11 RES-CHIP 47K 5% 1/16W
R008 1-240-726-91 METAL CHIP 470K 5% 1/20W
R009 1-218-985-11 RES-CHIP 470K 5% 1/16W
R010 1-218-989-11 RES-CHIP 1M 5% 1/16W
R011 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
* R012 1-245-673-11 METAL CHIP 330K 0.5% 1/20W
* R013 1-240-828-11 METAL CHIP 82K 0.5% 1/20W
R014 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R015 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R016 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R017 1-240-826-91 METAL CHIP 68K 0.5% 1/20W
R018 1-240-820-11 METAL CHIP 33K 0.5% 1/20W
R019 1-240-822-11 METAL CHIP 47K 0.5% 1/20W
Note: Short chips are mounted to the location where
FB281 and L101 are printed.
