6
Locations of Controls
FCB-EX48C/EX48CP Main Unit
1 Lens
2 CN991 connector
3 CN992 connector
4 CN601 connector (for key SW)
5 TELE button
6 WIDE button
7 Tripod screw holes
When a tripod is used, please use
10 mm (
13
/32 in.) screws to attach it
to the camera. Also, please be
sure to attach the tripod securely.
Front
Rear Bottom
Left side
7
3
2
1
6
5
4
