– 93 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PANEL
R674 1-216-049-91 RES,CHIP 1K 5% 1/10W
R675 1-216-073-00 METAL CHIP 10K 5% 1/10W
R676 1-216-089-91 RES,CHIP 47K 5% 1/10W
R677 1-216-089-91 RES,CHIP 47K 5% 1/10W
R678 1-216-073-00 METAL CHIP 10K 5% 1/10W
R680 1-216-073-00 METAL CHIP 10K 5% 1/10W
R681 1-216-073-00 METAL CHIP 10K 5% 1/10W
R682 1-216-073-00 METAL CHIP 10K 5% 1/10W
R683 1-216-073-00 METAL CHIP 10K 5% 1/10W
R684 1-216-073-00 METAL CHIP 10K 5% 1/10W
R685 1-216-073-00 METAL CHIP 10K 5% 1/10W
R686 1-216-097-91 RES,CHIP 100K 5% 1/10W
R687 1-216-097-91 RES,CHIP 100K 5% 1/10W
R688 1-216-073-00 METAL CHIP 10K 5% 1/10W
R689 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R691 1-216-097-91 RES,CHIP 100K 5% 1/10W
R692 1-216-097-91 RES,CHIP 100K 5% 1/10W
R693 1-216-097-91 RES,CHIP 100K 5% 1/10W
R694 1-216-097-91 RES,CHIP 100K 5% 1/10W
R695 1-216-097-91 RES,CHIP 100K 5% 1/10W
R696 1-216-097-91 RES,CHIP 100K 5% 1/10W
R697 1-216-097-91 RES,CHIP 100K 5% 1/10W
R698 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R699 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R701 1-216-017-91 RES,CHIP 47 5% 1/10W
(GRX80:EA3)
R711 1-216-081-00 METAL CHIP 22K 5% 1/10W
(GRX80:EA3)
R712 1-216-081-00 METAL CHIP 22K 5% 1/10W
(GRX80:EA3)
R713 1-216-081-00 METAL CHIP 22K 5% 1/10W
(GRX80:EA3)
R714 1-216-089-91 RES,CHIP 47K 5% 1/10W
(GRX80:EA3)
R715 1-216-081-00 METAL CHIP 22K 5% 1/10W
(GRX80:EA3)
R716 1-216-077-00 METAL CHIP 15K 5% 1/10W
(GRX80:EA3)
R717 1-216-081-00 METAL CHIP 22K 5% 1/10W
(GRX80:EA3)
R718 1-216-081-00 METAL CHIP 22K 5% 1/10W
(GRX80:EA3)
R719 1-216-099-00 METAL CHIP 120K 5% 1/10W
(GRX80:EA3)
R721 1-216-073-00 METAL CHIP 10K 5% 1/10W
R722 1-216-049-91 RES,CHIP 1K 5% 1/10W
R723 1-216-097-91 RES,CHIP 100K 5% 1/10W
R724 1-216-049-91 RES,CHIP 1K 5% 1/10W
R725 1-216-081-00 METAL CHIP 22K 5% 1/10W
R725 1-216-089-91 RES,CHIP 47K 5% 1/10W
(GRX80:EA3)
R726 1-216-073-00 METAL CHIP 10K 5% 1/10W
R727 1-216-077-00 METAL CHIP 15K 5% 1/10W
(GRX80:EA3)
R728 1-216-103-00 METAL CHIP 180K 5% 1/10W
R729 1-216-025-91 RES,CHIP 100 5% 1/10W
R751 1-216-029-00 METAL CHIP 150 5% 1/10W
R752 1-216-029-00 METAL CHIP 150 5% 1/10W
R753 1-216-029-00 METAL CHIP 150 5% 1/10W
R754 1-216-029-00 METAL CHIP 150 5% 1/10W
R758 1-216-022-00 METAL CHIP 75 5% 1/10W
R759 1-216-022-00 METAL CHIP 75 5% 1/10W
R760 1-216-022-00 METAL CHIP 75 5% 1/10W
R761 1-216-022-00 METAL CHIP 75 5% 1/10W
R762 1-216-029-00 METAL CHIP 150 5% 1/10W
R763 1-216-029-00 METAL CHIP 150 5% 1/10W
R764 1-216-019-00 METAL CHIP 56 5% 1/10W
R765 1-216-019-00 METAL CHIP 56 5% 1/10W
R766 1-216-029-00 METAL CHIP 150 5% 1/10W
R767 1-216-022-00 METAL CHIP 75 5% 1/10W
R768 1-216-029-00 METAL CHIP 150 5% 1/10W
R769 1-216-029-00 METAL CHIP 150 5% 1/10W
R770 1-216-029-00 METAL CHIP 150 5% 1/10W
R771 1-216-029-00 METAL CHIP 150 5% 1/10W
R772 1-216-029-00 METAL CHIP 150 5% 1/10W
R773 1-216-022-00 METAL CHIP 75 5% 1/10W
R775 1-216-029-00 METAL CHIP 150 5% 1/10W
R776 1-216-019-00 METAL CHIP 56 5% 1/10W
R777 1-216-025-91 RES,CHIP 100 5% 1/10W
R778 1-216-025-91 RES,CHIP 100 5% 1/10W
R780 1-216-073-00 METAL CHIP 10K 5% 1/10W
R781 1-216-029-00 METAL CHIP 150 5% 1/10W
R782 1-216-029-00 METAL CHIP 150 5% 1/10W
R783 1-216-073-00 METAL CHIP 10K 5% 1/10W
R784 1-216-081-00 METAL CHIP 22K 5% 1/10W
R785 1-216-081-00 METAL CHIP 22K 5% 1/10W
R786 1-216-049-91 RES,CHIP 1K 5% 1/10W
R787 1-216-095-00 METAL CHIP 82K 5% 1/10W
R788 1-216-089-91 RES,CHIP 47K 5% 1/10W
R789 1-216-095-00 METAL CHIP 82K 5% 1/10W
R790 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
< VARIABLE RESISTOR >
RV711 1-225-739-11 RES, VAR 50K (GRX80:EA3)
RV712 1-225-739-11 RES, VAR 50K
< SWITCH >
S601 1-473-534-11 ENCODER, ROTARY (JOG/0 ˜ ))
S602 1-473-392-11 ENCODER, ROTARY (VOLUME)
S611 1-762-875-21 SWITCH, KEYBOARD (SYNC BASE)
S612 1-762-875-21 SWITCH, KEYBOARD (SYNC EQ)
S613 1-762-875-21 SWITCH, KEYBOARD (KARAOKE PON/MPX)
S614 1-762-875-21 SWITCH, KEYBOARD (NON STOP)
S615 1-762-875-21 SWITCH, KEYBOARD (SURROUND)
S616 1-762-875-21 SWITCH, KEYBOARD (DBFB)
S617 1-762-875-21 SWITCH, KEYBOARD (ENTER/NEXT)
S618 1-762-875-21 SWITCH, KEYBOARD (+/))
S619 1-762-875-21 SWITCH, KEYBOARD (-/0)
S620 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S621 1-762-875-21 SWITCH, KEYBOARD (PAD B)
S622 1-762-875-21 SWITCH, KEYBOARD (BEAT SPEED)
S623 1-762-875-21 SWITCH, KEYBOARD (BEAT SEL)
S624 1-762-875-21 SWITCH, KEYBOARD (BEAT ON/OFF)
S625 1-762-875-21 SWITCH, KEYBOARD (REC)
S626 1-762-875-21 SWITCH, KEYBOARD (HI DVB)
