– 94 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S627 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S628 1-762-875-21 SWITCH, KEYBOARD (PAD A)
S629 1-762-875-21 SWITCH, KEYBOARD (BEAT MIX)
S630 1-762-875-21 SWITCH, KEYBOARD (BEAT JAM)
S631 1-762-875-21 SWITCH, KEYBOARD (BEAT LEVEL)
S636 1-762-875-21 SWITCH, KEYBOARD (AUTO BPM)
S637 1-762-875-21 SWITCH, KEYBOARD (FLASH)
S638 1-762-875-21 SWITCH, KEYBOARD (P FILE MEMORY)
S639 1-762-875-21 SWITCH, KEYBOARD (GEQ CONTROL)
S640 1-762-875-21 SWITCH, KEYBOARD (FILE SELECT)
S641 1-762-875-21 SWITCH, KEYBOARD (EFFECT)
S642 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S643 1-762-875-21 SWITCH, KEYBOARD (^)
S644 1-762-875-21 SWITCH, KEYBOARD (p)
S645 1-762-875-21 SWITCH, KEYBOARD (B:()
S646 1-762-875-21 SWITCH, KEYBOARD (B:9)
S647 1-762-875-21 SWITCH, KEYBOARD (A:()
S648 1-762-875-21 SWITCH, KEYBOARD (A:9)
S649 1-762-875-21 SWITCH, KEYBOARD (FANCTION)
S650 1-762-875-21 SWITCH, KEYBOARD (LOOP)
S651 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S652 1-762-875-21 SWITCH, KEYBOARD (CLOCK/TIME SET)
S653 1-762-875-21 SWITCH, KEYBOARD (TIME SELECT)
S654 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM ANALYZER)
S655 1-762-875-21 SWITCH, KEYBOARD (REPEAT STEREO/MONO)
S656 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE DOLBY ON)
S657 1-762-875-21 SWITCH, KEYBOARD
(EDIT DIRECTION TUNER MEMORY)
< VIBRATOR >
X601 1-781-312-11 VIBRATOR, CERAMIC (12.5MHz)
X602 1-767-353-11 VIBRATOR, CERAMIC (4.98MHz)
**************************************************************
* 1-658-576-11 SENSOR BOARD
************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
**************************************************************
* A-4417-646-A SUB TRANS BOARD, COMPLETE (RXD8/RXD8S)
**************************
< CAPACITOR >
C11 1-126-768-11 ELECT 2200uF 20% 16V
C12 1-161-494-00 CERAMIC 0.022uF 25V
C13 1-126-933-11 ELECT 100uF 20% 16V
C14 1-126-968-11 ELECT 100uF 20% 50V
C15 1-164-159-11 CERAMIC 0.1uF 50V
C16 1-126-948-11 ELECT 100uF 20% 35V
! C21 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
CN11 1-564-321-00 PIN, CONNECTOR 2P
* CN12 1-564-321-21 PIN, CONNECTOR 2P
CN13 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE)7P
< DIODE >
D11 8-719-911-19 DIODE 1SS119-25
D12 8-719-210-21 DIODE 11EQS04
D13 8-719-210-21 DIODE 11EQS04
D14 8-719-210-21 DIODE 11EQS04
D15 8-719-210-21 DIODE 11EQS04
D16 8-719-911-19 DIODE 1SS119-25
D17 8-719-024-99 DIODE 11ES2-NTA2B
D18 8-719-024-99 DIODE 11ES2-NTA2B
D19 8-719-024-99 DIODE 11ES2-NTA2B
D20 8-719-024-99 DIODE 11ES2-NTA2B
D21 8-719-986-60 DIODE HZS27-3LTA
D22 8-719-109-63 DIODE RD3.0ESB2
D23 8-719-911-19 DIODE 1SS119-25
< IC >
IC11 8-759-450-47 IC BA05T
< TRANSISTOR >
Q11 8-729-119-78 TRANSISTOR 2SC403SP-51
Q12 8-729-040-19 TRANSISTOR RT1N137L-TP
Q13 8-729-118-01 TRANSISTOR 2SB1116
Q14 8-729-048-13 TRANSISTOR 2SC3616-KLM-T1
Q15 8-729-048-13 TRANSISTOR 2SC3616-KLM-T1
Q16 8-729-900-63 TRANSISTOR DTA124ES
Q17 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R11 1-249-429-11 CARBON 10K 5% 1/4W
R12 1-249-429-11 CARBON 10K 5% 1/4W
R13 1-249-417-11 CARBON 1K 5% 1/4W F
R15 1-249-429-11 CARBON 10K 5% 1/4W
R16 1-247-807-31 CARBON 100 5% 1/4W
R17 1-247-807-31 CARBON 100 5% 1/4W
R18 1-247-807-31 CARBON 100 5% 1/4W
R19 1-249-417-11 CARBON 1K 5% 1/4W F
R20 1-247-807-31 CARBON 100 5% 1/4W
< RELAY >
! RY11 1-755-276-11 RELAY, POWER
< TRANSFORMER >
! T11 1-433-591-11 TRANSFORMER, POWER
**************************************************************
* 1-672-474-11 TRANS BOARD
***********
< CAPACITOR >
C971 1-128-563-11 ELECT 100uF 20% 100V
(GRX80)
C972 1-126-960-11 ELECT 1uF 20% 50V
(GRX80)
SUB TRANS
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
