Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
TRANS
C973 1-126-947-11 ELECT 47uF 20% 35V
(GRX80)
< CONNECTOR >
CN901 1-564-524-11 PLUG, CONNECTOR 9P (RXD8/RXD8S)
* CN901 1-564-527-11 PLUG, CONNECTOR 12P (GRX80)
CN902 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P (GRX80)
CN951 1-564-321-00 PIN, CONNECTOR 2P (GRX80)
< DIODE >
D971 8-719-024-99 DIODE 11ES2-NTA2B (GRX80)
D972 8-719-056-97 DIODE UDZ-TE-17-27B (GRX80)
D973 8-719-056-74 DIODE UDZ-TE-17-3.0B (GRX80)
< FUSE >
! F951 1-532-506-31 FUSE (T6.3AL/250V)
(GRX80:E2,E3,EA3,SP,AR,TW,MX)
! F952 1-532-465-31 FUSE (3.15A/250V)
(GRX80:E2,E3,EA3,SP,AR,TW,AUS,EA4,TH)
! F953 1-532-465-31 FUSE (3.15A/250V)
(GRX80:E2,E3,EA3,SP,AR,TW,AUS,EA4,TH)
! F961 1-532-505-31 FUSE (T5AL/250V)(GRX80)
! F962 1-532-505-31 FUSE (T5AL/250V)(GRX80)
! F963 1-533-949-31 FUSE, CYLINDRICAL (T8AL/250V)(RXD8/RXD8S)
! F964 1-533-949-31 FUSE, CYLINDRICAL (T8AL/250V)(RXD8/RXD8S)
< FUSE HOLDER >
FH951 1-533-233-21 HOLDER, FUSE
(GRX80:E2,E3,EA3,SP,AR,TW,MX)
FH952 1-533-233-21 HOLDER, FUSE
(GRX80:E2,E3,EA3,SP,AR,TW,MX)
FH953 1-533-233-21 HOLDER, FUSE
(GRX80:E2,E3,EA3,SP,AR,TW,EA4,TH)
FH954 1-533-233-21 HOLDER, FUSE
(GRX80:E2,E3,EA3,SP,AR,TW,EA4,TH)
FH955 1-533-233-21 HOLDER, FUSE
(GRX80:E2,E3,EA3,SP,AR,TW,AUS)
FH956 1-533-233-21 HOLDER, FUSE
(GRX80:E2,E3,EA3,SP,AR,TW,AUS)
FH961 1-533-233-21 HOLDER, FUSE (GRX80)
FH962 1-533-233-21 HOLDER, FUSE (GRX80)
FH963 1-533-233-21 HOLDER, FUSE (GRX80)
FH964 1-533-233-21 HOLDER, FUSE (GRX80)
FH965 1-533-233-21 HOLDER, FUSE (RXD8/RXD8S)
FH966 1-533-233-21 HOLDER, FUSE (RXD8/RXD8S)
FH967 1-533-233-21 HOLDER, FUSE (RXD8/RXD8S)
FH968 1-533-233-21 HOLDER, FUSE (RXD8/RXD8S)
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932(TP)(GRX80)
< RESISTOR >
! R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(GRX80)
! R951 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
(RXD8/RXD8S)
! R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(GRX80)
! R952 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
(RXD8/RXD8S)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
! R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(RXD8/RXD8S)
! R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(GRX80)
R971 1-216-455-11 METAL OXIDE 560 5% 2W F
(GRX80)
R972 1-216-085-00 METAL CHIP 33K 5% 1/10W
(GRX80)
R973 1-216-073-00 METAL CHIP 10K 5% 1/10W
(GRX80)
R974 1-216-025-91 RES,CHIP 100 5% 1/10W
(GRX80)
R975 1-216-025-91 RES,CHIP 100 5% 1/10W
(GRX80)
R976 1-216-085-00 METAL CHIP 33K 5% 1/10W
(GRX80)
R977 1-216-085-00 METAL CHIP 33K 5% 1/10W
(GRX80)
< SWITCH >
S951 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
(GRX80:E2,E3,EA3,SP,AR,TW)
< TRANSFORMER >
! T951 1-433-556-11 TRANSFORMER, POWER (GRX80)
! T951 1-433-557-11 TRANSFORMER, POWER (RXD8/RXD8S)
**************************************************************
MISCELLANEOUS
*************
5 1-233-545-11 TUNER UNIT (EA4,TH)
5 1-233-545-14 ENCAPSULATED COMPONENT (E2,AR,MX,AUS)
5 1-233-546-13 ENCAPSULATED COMPONENT (E3,EA3,SP,TW)
5 1-693-443-11 TUNER UNIT (AEP,UK,G,CIS)
54 1-783-570-11 WIRE (FLAT TYPE)(19 CORE)
55 1-769-977-11 WIRE (FLAT TYPE)(13 CORE)
55 1-773-009-11 WIRE (FLAT TYPE)(15 CORE)(150mm)
56 1-773-024-11 WIRE (FLAT TYPE)(15 CORE)(320mm)
58 1-569-007-11 ADAPTOR, CONVERSION 2P (E3)
58 1-569-008-21 ADAPTOR, CONVERSION 2P (EA3,SP,TW)
58 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
! 59 1-575-651-11 CORD, POWER (AEP,UK,G,CIS,EA3,SP,TW)
! 59 1-575-653-11 CORD, POWER (E2,E3,MX,TH)
! 59 1-690-608-11 CORD, POWER (AUS)
! 59 1-783-721-11 CORD, POWER (EA4)
! 59 1-783-941-21 CORD, POWER (GRX80:AR)
62 1-773-042-11 WIRE (FLAT TYPE)(17 CORE)
116 1-773-223-11 WIRE (FLAT TYPE)(25 CORE)
257 1-452-925-21 MAGNET ASSY
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
FL601 1-517-831-11 INDICATOR TUBE, FLUORESCENT
HP101 A-2056-681-A DECK (A) ASSY, HEAD (230AWR2)
HP101 A-2056-681-B DECK (A) ASSY, HEAD (230PWR2)
HRPE101 A-2056-682-A DECK (B) ASSY, HEAD (230AWR2)
HRPE101 A-2056-682-B DECK (B) ASSY, HEAD (230PWR2)
