– 96 –
HCD-GRX80/RXD8/RXD8S
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
Ref. No. Part No. Description Remark
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-4917-523-3 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M701 A-4672-004-A MOTOR ASSY
M901 1-763-072-11 FAN, D.C.
S811 1-473-335-11 ENCODER, ROTARY
! T11 1-433-591-11 TRANSFORMER, POWER (RXD8/RXD8S)
! T951 1-433-556-11 TRANSFORMER, POWER (GRX80)
! T951 1-433-557-11 TRANSFORMER, POWER (RXD8/RXD8S)
**************************************************************
*************
HARDWARE LIST
*************
#1 7-685-871-01 SCREW +BVTT 3X6 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-880-09 SCREW +BVTT 4X6 (S)
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#5 7-685-852-04 SCREW +BVTT 2X5 (S)
#7 7-682-553-04 SCREW +P 3X20
#8 7-685-851-04 SCREW +BVTT 2X4 (S)
#9 7-628-254-15 SCREW +PS 2.6X6
#10 7-628-254-50 SCREW +PS 2.6X16
#11 7-685-861-01 SCREW +BVTT 2.6X5 (S)
