91
HCD-S500/S800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
I/O
< CONNECTOR >
* CN600 1-569-930-11 SOCKET, CONNECTOR 13P (S500:AEP,UK)
CN600 1-794-431-11 CONNECTOR, FFC/FPC 13P
(EXCEPT S500:AEP,UK)
CN601 1-779-566-11 CONNECTOR,FFC(LIF(NON-ZIF))29P
(S500:AEP,UK)
CN601 1-779-297-11 CONNECTOR,FFC(LIF(NON-ZIF))29P
(EXCEPT S500:AEP,UK)
CN700 1-779-546-11 CONNECTOR, FFC(LIF(NON-ZIF))9P
< DIODE >
D601 8-719-056-85 DIODE UDZSTE-178.2B
D602 8-719-056-78 DIODE UDZ-TE-17-4.3B
(S500:AEP,CIS,UK/S800)
< IC >
IC600 8-759-385-76 IC MC14052 BDR2
IC601 8-759-646-52 IC KIA7805AP (EXCEPT S500:AEP,UK)
IC601 8-759-701-56 IC NJM78M05FA (EXCEPT S500:AEP,UK)
IC602 8-749-923-05 TORX178B (VIDEO2/OPTICAL DIGITAL IN)
IC603 8-749-923-04 IC TOTX178A (DIGITAL OUT/OPTICAL)
IC604 8-759-557-36 IC BU1924F-E2 (S500:AEP,CIS,UK/S800)
IC700 8-759-696-10 IC NJM2235V(TE2)
IC701 8-759-680-28 IC BA7666FS-E2
IC702 8-759-284-49 IC NJM2285V-TE2
< JACK >
J600 1-815-747-11 JACK, PIN 9P (VIDEO AUDIO IN/OUT
VIDEO IN/OUT/VIDEO2 AUDIO IN VIDEO IN)
J700 1-815-748-11 JACK, PIN 2P (MONITOR OUT/S VIDEO/VIDEO)
< COIL >
L600 1-216-295-00 SHORT 0
L601 1-469-525-91 INDUCTOR 10uH
L700 1-412-939-11 INDUCTOR 1uH (S500:AEP,UK)
L700 1-412-953-11 INDUCTOR 15uH (EXCEPT S500:AEP,UK)
L702 1-469-525-91 INDUCTOR 10uH
L703 1-412-939-11 INDUCTOR 1uH (S500:AEP,UK)
L703 1-412-953-11 INDUCTOR 15uH (EXCEPT S500:AEP,UK)
L705 1-412-939-11 INDUCTOR 1uH (S500:AEP,UK)
L705 1-412-953-11 INDUCTOR 15uH (EXCEPT S500:AEP,UK)
L707 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q600 8-729-801-93 TRANSISTOR 2SD1387-34-TP
Q601 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q602 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q603 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q604 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q605 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q606 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q607 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
(S500:AEP,CIS,UK/S800)
Q700 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q701 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q702 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q703 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q704 1-801-806-11 TRANSISTOR DTC144EKA-T146
< RESISTOR >
R600 1-216-033-00 METAL CHIP 220 5% 1/10W
(S500:AEP,UK)
R600 1-216-813-11 METAL CHIP 220 5% 1/16W
(EXCEPT S500:AEP,UK)
R601 1-216-033-00 METAL CHIP 220 5% 1/10W
(S500:AEP,UK)
R601 1-216-813-11 METAL CHIP 220 5% 1/16W
(EXCEPT S500:AEP,UK)
R602 1-216-033-00 METAL CHIP 220 5% 1/10W
(S500:AEP,UK)
R602 1-216-813-11 METAL CHIP 220 5% 1/16W
(EXCEPT S500:AEP,UK)
R603 1-216-033-00 METAL CHIP 220 5% 1/10W
(S500:AEP,UK)
R603 1-216-813-11 METAL CHIP 220 5% 1/16W
(EXCEPT S500:AEP,UK)
R604 1-216-033-00 METAL CHIP 220 5% 1/10W
(S500:AEP,UK)
R604 1-216-813-11 METAL CHIP 220 5% 1/16W
(EXCEPT S500:AEP,UK)
R605 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(S500:AEP,UK)
R605 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(EXCEPT S500:AEP,UK)
R606 1-216-066-00 METAL CHIP 5.1K 5% 1/10W
(S500:AEP,UK)
R606 1-218-272-11 RES-CHIP 5.1K 5% 1/16W
(EXCEPT S500:AEP,UK)
R607 1-216-066-00 METAL CHIP 5.1K 5% 1/10W
(S500:AEP,UK)
R607 1-218-272-11 RES-CHIP 5.1K 5% 1/16W
(EXCEPT S500:AEP,UK)
R608 1-216-295-00 SHORT 0 (S500:AEP,UK)
R608 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT S500:AEP,UK)
R609 1-216-073-00 RES-CHIP 10K 5% 1/10W
(S500:AEP,UK)
R609 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT S500:AEP,UK)
R610 1-216-073-00 RES-CHIP 10K 5% 1/10W
(S500:AEP,UK)
R610 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT S500:AEP,UK)
R611 1-216-025-11 RES-CHIP 100 5% 1/10W
(S500:AEP,UK)
R611 1-216-809-11 METAL CHIP 100 5% 1/16W
(EXCEPT S500:AEP,UK)
R612 1-216-073-00 RES-CHIP 10K 5% 1/10W
(S500:AEP,UK)
R612 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT S500:AEP,UK)
R613 1-216-073-00 RES-CHIP 10K 5% 1/10W
(S500:AEP,UK)
R613 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT S500:AEP,UK)
R614 1-216-025-11 RES-CHIP 100 5% 1/10W
(S500:AEP,UK)
R614 1-216-809-11 METAL CHIP 100 5% 1/16W
(EXCEPT S500:AEP,UK)
