98
HCD-S500/S800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
SW(A)-1030 SW(B)-1030
1-681-995-11 RR-1030 BOARD
*************
< CAPACITOR >
C808 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< IC >
IC101 8-759-827-70 IC NJL64H400A-1
< RESISTOR >
R815 1-216-805-11 METAL CHIP 47 5% 1/16W
************************************************************
1-681-992-11 SW (A)-1030 BOARD
*****************
< CONNECTOR >
CN810 1-506-481-11 PIN, CONNECTOR 2P
< RESISTOR >
R800 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R801 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R802 1-216-835-11 METAL CHIP 15K 5% 1/16W
R803 1-216-841-11 METAL CHIP 47K 5% 1/16W
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (x)
S802 1-762-875-21 SWITCH, KEYBOARD (X)
S803 1-762-875-21 SWITCH, KEYBOARD (PRESET+ / NEXT >)
S804 1-762-875-21 SWITCH, KEYBOARD (G)
S805 1-762-875-21 SWITCH, KEYBOARD (PRESET- / PREV.)
************************************************************
1-681-993-11 SW (B)-1030 BOARD
*****************
< CONNECTOR >
CN812 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S806 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE A)
************************************************************
MISCELLANEOUS
**************
0 7 1-690-608-11 CORD, POWER (E12,E32,AUS)
0 7 1-696-169-21 CORD, POWER (AEP,CIS,UK,EA,MY,SP,HK,TW)
0 7 1-769-079-21 CORD, POWER (KR)
0 7 1-775-789-91 CORD, POWER (MX)
0 7 1-783-532-11 CORD, POWER (US,CND)
0 7 1-783-941-21 CORD, POWER (AR)
65 1-823-076-11 CABLE, FLEXIBLE FLAT (15 CORE)
69 1-786-210-11 SWITCH, POWER (S500)
101 A-4726-404-A TUNER UNIT (US,CND)
101 A-4726-588-A TUNER UNIT (AEP,CIS,UK,KR,TW,AUS)
101 A-4726-594-A TUNER UNIT (MX)
101 A-4726-905-A TUNER UNIT (E12,E32,EA,HK,SP,MY,AR)
102 1-823-082-11 CABLE, FLEXIBLE FLAT (13 CORE)
104 1-823-079-11 CABLE, FLEXIBLE FLAT (29 CORE)
105 1-823-074-11 CABLE, FLEXIBLE FLAT (9 CORE)
111 1-823-075-11 CABLE, FLEXIBLE FLAT (12 CORE)
112 1-823-353-11 CABLE, FLEXIBLE FLAT (17 CORE)
114 1-823-354-11 CABLE, FLEXIBLE FLAT (25 CORE)
0 419 8-820-144-06 DEVICE,OPTICAL KHM-240AAA
420 1-823-072-11 CABLE, FLEXIBLE FLAT 26P
421 1-823-073-11 CABLE, FLEXIBLE FLAT (9 CORE)
M901 A-2004-893-A MOTOR (LD) ASSY
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-548-14 SCREW +BTP 3X12 TYPE2 N-S
#3 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
RR-1030
