Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
68
HCD-XG60/XG500
C598 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C599 1-104-664-11 ELECT 47uF 20% 16V
C601 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C602 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C603 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C604 1-126-961-11 ELECT 2.2uF 20% 50V
(XG60)
C604 1-126-963-11 ELECT 4.7uF 20% 50V
(XG500)
C605 1-130-479-00 MYLAR 0.0047uF 5% 50V
C606 1-130-473-00 MYLAR 0.0015uF 5% 50V
C607 1-136-159-00 FILM 0.033uF 5% 50V
(XG60)
C607 1-136-165-00 FILM 0.1uF 5% 50V
(XG500)
C608 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C609 1-126-933-11 ELECT 100uF 20% 16V
C651 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C652 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C653 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C654 1-126-961-11 ELECT 2.2uF 20% 50V
(XG60)
C654 1-126-963-11 ELECT 4.7uF 20% 50V
(XG500)
C655 1-130-479-00 MYLAR 0.0047uF 5% 50V
C656 1-130-473-00 MYLAR 0.0015uF 5% 50V
C657 1-136-159-00 FILM 0.033uF 5% 50V
(XG60)
C657 1-136-165-00 FILM 0.1uF 5% 50V
(XG500)
C658 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C659 1-126-933-11 ELECT 100uF 20% 16V
C699 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C701 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C702 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C703 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C704 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(US, CND, AEP, UK, MX)
C705 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(US, CND, AEP, UK, MX)
C721 1-126-960-11 ELECT 1uF 20% 50V
C722 1-126-926-11 ELECT 1000uF 20% 10V
C724 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C751 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C752 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C753 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C772 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C774 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C777 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C782 1-104-664-11 ELECT 47uF 20% 16V
C803 1-126-964-11 ELECT 10uF 20% 50V
C804 1-136-165-00 FILM 0.1uF 5% 50V
C805 1-136-165-00 FILM 0.1uF 5% 50V
C806 1-126-916-11 ELECT 1000uF 20% 6.3V
C808 1-109-953-11 ELECT 2.2uF 20% 50V
C902 1-126-937-11 ELECT 4700uF 20% 16V
C903 1-126-964-11 ELECT 10uF 20% 50V
C904 1-126-964-11 ELECT 10uF 20% 50V
C905 1-126-935-11 ELECT 470uF 20% 10V
C911 1-126-964-11 ELECT 10uF 20% 50V
C912 1-126-916-11 ELECT 1000uF 20% 6.3V
C913 1-104-664-11 ELECT 47uF 20% 16V
C914 1-126-916-11 ELECT 1000uF 20% 6.3V
C932 1-126-964-11 ELECT 10uF 20% 50V
C933 1-126-933-11 ELECT 100uF 20% 16V
C934 1-126-964-11 ELECT 10uF 20% 50V
C935 1-126-767-11 ELECT 1000uF 20% 16V
C936 1-126-964-11 ELECT 10uF 20% 50V
C937 1-126-933-11 ELECT 100uF 20% 16V
C938 1-126-933-11 ELECT 100uF 20% 16V
C952 1-126-943-11 ELECT 2200uF 20% 25V
C953 1-126-964-11 ELECT 10uF 20% 50V
C954 1-126-964-11 ELECT 10uF 20% 50V
C955 1-126-935-11 ELECT 470uF 20% 10V
C961 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(US, CND, E)
< CONNECTOR >
CN303 1-784-776-11 CONNECTOR, FFC 15P
CN304 1-784-778-11 CONNECTOR, FFC 17P
CN411 1-784-780-11 CONNECTOR, FFC 19P
CN412 1-785-321-11 PIN, CONNECTOR (STRAIGHT) 9P
CN431 1-784-774-11 CONNECTOR, FFC 13P
CN441 1-563-616-11 CONNECTOR, FLEXIBLE 13P (US, CND, E)
CN441 1-750-747-11 CONNECTOR, FFC/FPC 15P (AEP, UK)
CN452 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
CN702 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN901 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
CN902 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
CN903 1-564-506-11 PLUG, CONNECTOR 3P (US, CND, E)
< DIODE >
D191 8-719-988-61 DIODE 1SS355TE-17
D192 8-719-988-61 DIODE 1SS355TE-17
D193 8-719-988-61 DIODE 1SS355TE-17
D194 8-719-988-61 DIODE 1SS355TE-17
D501 8-719-988-61 DIODE 1SS355TE-17
D534 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-988-61 DIODE 1SS355TE-17
D804 8-719-988-61 DIODE 1SS355TE-17
D805 8-719-988-61 DIODE 1SS355TE-17
D806 8-719-988-61 DIODE 1SS355TE-17
D807 8-719-988-61 DIODE 1SS355TE-17
D808 8-719-210-33 DIODE EC10DS2
D911 8-719-988-61 DIODE 1SS355TE-17
D912 8-719-210-33 DIODE EC10DS2
D913 8-719-210-33 DIODE EC10DS2
D931 8-719-210-33 DIODE EC10DS2
D951 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB412 1-414-772-11 FERRITE 0uH
FB413 1-414-551-11 FERRITE 0uH
FB415 1-414-772-11 FERRITE 0uH
MAIN
