Help Guide
Portable Theatre System
HT-AX7
Specifications
Front Speaker (YY2078C1)
Speaker section
Full range unit
Approx. 49 mm × 71 mm (1 15/16 in × 2 7/8 in) (2)
Enclosure type
Passive radiator model
BLUETOOTH section
Communication system
BLUETOOTH Specification version 5.2
Maximum communication range
Line of sight approx. 30 m (98.4 ft)
1）
Frequency band
2.4 GHz band (2.400 0 GHz - 2.483 5 GHz)
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
2）
A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio Video Remote Control Profile)
HSP (Headset Profile)
HFP (Hands-free Profile)
Supported Codecs
3）
SBC (Subband Codec)
AAC (Advanced Audio Coding)
Transmission range (A2DP)
20 Hz - 20 000 Hz (Sampling frequency 44.1 kHz)
Note
Depending on the network environment, there may be an interruption at the high bitrate transmission.
Microphone
Type
Electret condenser
Directional characteristic
Omni directional
Effective frequency range
100 Hz - 7 000 Hz
General
Power consumption
2）
Approx. 45 W (while charging the built-in lithium-ion battery)
The actual range will vary depending on factors such as obstacles between devices, magnetic fields around a microwave oven, static electricity,
cordless phone use, reception sensitivity, the operating system, software applications, etc.
1）
BLUETOOTH standard profiles indicate the purpose of BLUETOOTH communication between devices.
2）
Codec: Audio signal compression and conversion format
3）
