• If you connect the audio output of the video
component and the system using other than
an HDM[ cable, no sound may be output
because of"BRAVIA" Sync. In this case, set
"CTRL HDM[" to "OFF" (page 20) or
connect the audio output jack directly to the
TV instead of the system.
If "PROTECTOR" and "PUSH POWER" appear
alternately in the front panel display.
Press I/(_) to turn offthe system, and check
the following item after "STANDBY"
disappears.
• Is anything blocking the ventilation holes of
the system?
After checking the above item and fixing
any problems, turn on the system. If the
cause of the problem cannot be found even
alter checking the above item. consult your
nearest Sony dealer.
If the system still does not
operate properly after performing
the above measures, reset the
system as follows:
Use buttons on the system for the operation.
1 Press I/_ to turn on the power.
2 Press I/_ while pressing INPUT
SELECTOR and VOLUME -.
"COLD RESET" appears and the system is
reset. AMP menu, sound field, etc., return to
the default settings.
Formats supported by this
system
Digital input formats supported by this system
are as follows.
Format Supported/Not supported
Dolby Digital O
DTS 0
Linear PCM (2ch)"= O
Linear PCM (5.1ch, O
7.1ch)"= (Only on
HDMI)
Dolby Digital Plus x
Dolby True HD x
DTS-HD x
* Linear PCM accepts sampling frequencies of no
more than 48 kHz.
Amplifier section
POWER OUTPUT (rated)
Front L/Front R: 60 W + 60 W (at 4 ohms,
1 kHz, 1% THD)
POWER OUTPUT (reference)
Front L/Front R/Center: 85 W (per channel at
4 ohms, 1 kHz)
Subwoofer: 85 W (at 4 ohms, 100 Hz)
Inputs
TV, SA-CD/CD Analog
TV, SAT/CATV Digital (Optical)
VIDEO Digital (Coaxial)
HDMI section
Connector
Video inputs/outputs
HDMI TM connector
BD, DVD, SAT/CATV;
640 x 480p@60 Hz
720 x 480p@59.94/60 Hz
1280 x 720p@59.94/60 Hz
1920 x 1080i@59.94/60 Hz
1920 x 1080p @59.94/60 Hz
720 x 576p@50 Hz
1280 x 720p@50 Hz
1920 x 1080i@50 Hz
1920 x 1080p@50 Hz
1920 x 1080p@24 Hz
1>
u,
o
-',1
o
3
o
continued
35GB
