[2] Names of parts/Icons and indicators Names of parts
Rear side
Mode dial lock release button
11.
Mode dial
12.
C2 button (Custom button 2)
13.
Mounting index
14.
Lens release button
15.
Front multi-controller
16.
Front multi-controller click switch
17.
Do not directly touch these parts.
*
Do not cover this part during movie recording. Doing so may cause noise or lower the volume.
**
Diopter-adjustment dial
Adjust the diopter-adjustment dial according to your eyesight until the display appears
clearly in the viewfinder. If it is hard to operate the diopter-adjustment dial, remove the
eyepiece cup before operating the dial.
1.
Eye sensor
2.
Eyepiece cup
To remove the eyepiece cup
Grasp the eyepiece cup on the left and right sides and lift it up.
3.
To Next Page
