CTV41 61
Chapter 3. Disassembly
FIGURE 3-3
26
/32 PANEL REMOVAL (STEP 1)
STAND SCREWS
STAND BRACKET
COVER SCREWS
FIGURE 3-3
26/32” PANEL REMOVAL (STEP 1)
