8
Adjusting the viewing angle (except 60-inch models)
This TV can be adjusted within the angles shown below.
For KDL-52/46NX800 and KDL-46/40NX700
~
• Reverse the steps when readjusting the angle back to 0 degree.
For KDL-55NX811, KDL-55/46NX810, KDL-46/40NX711 and KDL-46/
40NX710
1
4
2
3
Remove screw as
shown.
6°
0°
Install screw into the
top screw hole of the
Table-Top Stand.
Slide in.
Lift up and tilt.
0° 6°
