— 68 —
KP- 43T85T / 53SV85T / 61SV85T
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
CG
* A-1331-923-A CG BOARD, MOUNTED
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C731 1-126-947-11 ELECT 47µF 20% 25V
C732 1-104-570-11 CERAMIC 0.001µF 10% 2KV
C733 1-102-114-00 CERAMIC 470pF 10% 50V
C734 1-102-114-00 CERAMIC 470pF 10% 50V
C735 1-101-880-00 CERAMIC 47pF 5% 50V
C736 1-161-830-00 CERAMIC .0047µF 500V
C737 1-162-115-00 CERAMIC 330pF 10% 2KV
C738 1-107-662-11 ELECT 22µF 20% 250V
C1301 1-104-987-11 MYLAR 0.001µF 10% 200V
C1302 1-107-639-11 ELECT 47µF 20% 160V
C1303 1-126-933-11 ELECT 100µF 20% 16V
C1305 1-126-933-11 ELECT 100µF 20% 16V
C1308 1-106-383-00 MYLAR 0.047µF 10% 200V
C1309 1-106-383-00 MYLAR 0.047µF 10% 200V
C1310 1-126-960-11 ELECT 1µF 20% 50V
C1312 1-161-830-00 CERAMIC .0047µF 500V
C1313 1-102-129-00 CERAMIC 0.01µF 10% 50V
C1314 1-102-129-00 CERAMIC 0.01µF 10% 50V
C1315 1-126-933-11 ELECT 100µF 20% 16V
CONNECTOR
* CN731 1-564-512-11 PLUG,CONNECTOR 9P
* CN732 1-564-507-11 PLUG,CONNECTOR 4P
* CN733 1-564-508-11 PLUG,CONNECTOR 5P
* CN734 1-764-333-11 PLUG,CONNECTOR 10P
* CN735 1-564-512-11 PLUG,CONNECTOR 9P
* CN736 1-564-512-11 PLUG,CONNECTOR 9P
CN737 1-785-879-11 CONNECTOR, ONE TOUCH
CN738 1-695-915-11 TAB (CONTACT)
CN739 1-695-915-11 TAB (CONTACT)
! CN740 1-251-182-11 SOCKET, CRT
* CN1301 1-564-506-11 PLUG,CONNECTOR 3P
* CN1302 1-564-506-11 PLUG,CONNECTOR 3P
* CN1303 1-564-506-11 PLUG,CONNECTOR 3P
* CN1304 1-564-509-11 PLUG,CONNECTOR 6P
DIODE
D731 8-719-991-33 DIODE 1SS133T-77
D732 8-719-991-33 DIODE 1SS133T-77
D733 8-719-991-33 DIODE 1SS133T-77
D734 8-719-991-33 DIODE 1SS133T-77
D735 8-719-991-33 DIODE 1SS133T-77
D736 8-719-109-85 DIODE MTZJ-T-77-5.1B
D1304 8-719-991-33 DIODE 1SS133T-77
COIL
L731 1-414-188-41 INDUCTOR 68µH
L732 1-412-911-11 FERRITE 0µH
L1301 1-412-911-11 FERRITE 0µH
L1302 1-412-911-11 FERRITE 0µH
NEON LAMP
NL731 1-517-778-21 LAMP, NEON
TRANSISTOR
Q731 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q732 8-729-326-11 TRANSISTOR 2SC3271F-N
Q733 8-729-200-17 TRANSISTOR 2SA1091O-TPE2
Q734 8-729-119-76 TRANSISTOR 2SA1309A-QRSTA
Q1301 8-729-017-06 TRANSISTOR 2SC4793
Q1302 8-729-017-05 TRANSISTOR 2SA1837
Q1303 8-729-119-76 TRANSISTOR 2SA1309A-QRSTA
Q1304 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q1305 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q1306 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R731 1-219-743-11 CARBON 100 5% 1/2W
R732 1-260-132-11 CARBON 560K 5% 1/2W
R733 1-247-807-31 CARBON 100 5% 1/4W
R734 1-260-087-11 CARBON 100 5% 1/2W
R735 1-249-403-11 CARBON 68 5% 1/4W
R736 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R737 1-249-393-11 CARBON 10 5% 1/4W
R738 1-249-414-11 CARBON 560 5% 1/4W
R739 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R741 1-249-425-11 CARBON 4.7K 5% 1/4W
R742 1-260-328-11 CARBON 1K 5% 1/2W
R743 1-247-881-00 CARBON 120K 5% 1/4W
R744 1-260-133-11 CARBON 680K 5% 1/2W
CG
