— 69 —
KP- 43T85T / 53SV85T / 61SV85T
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
R745 1-260-328-11 CARBON 1K 5% 1/2W
R746 1-249-437-11 CARBON 47K 5% 1/4W
R747 1-249-438-11 CARBON 56K 5% 1/4W
R753 1-412-911-11 FERRITE 0µH
R1301 1-215-916-00 METAL OXIDE 680 5% 3W
R1302 1-215-916-00 METAL OXIDE 680 5% 3W
R1303 1-249-400-11 CARBON 39 5% 1/4W
R1304 1-249-391-11 CARBON 6.8 5% 1/4W
R1305 1-249-391-11 CARBON 6.8 5% 1/4W
R1306 1-249-429-11 CARBON 10K 5% 1/4W
R1307 1-260-311-11 CARBON 39 5% 1/2W
R1308 1-249-419-11 CARBON 1.5K 5% 1/4W
R1310 1-249-441-11 CARBON 100K 5% 1/4W
R1311 1-249-419-11 CARBON 1.5K 5% 1/4W
R1314 1-249-419-11 CARBON 1.5K 5% 1/4W
R1315 1-249-399-11 CARBON 33 5% 1/4W
R1319 1-249-413-11 CARBON 470 5% 1/4W
R1321 1-249-406-11 CARBON 120 5% 1/4W
R1323 1-249-377-11 CARBON 0.47 5% 1/4W
R1324 1-249-425-11 CARBON 4.7K 5% 1/4W
R1325 1-249-431-11 CARBON 15K 5% 1/4W
R1327 1-249-441-11 CARBON 100K 5% 1/4W
R1328 1-249-435-11 CARBON 33K 5% 1/4W
SPARK GAP
SG731 1-519-422-11 GAP, SPARK
SG732 1-517-729-31 GAP, SPARK
CB
* A-1331-924-A CB BOARD, MOUNTED
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C761 1-126-947-11 ELECT 47µF 20% 25V
C762 1-104-570-11 CERAMIC 0.001µF 10% 2KV
C763 1-102-114-00 CERAMIC 470pF 10% 50V
C764 1-102-112-00 CERAMIC 330pF 10% 50V
C765 1-101-880-00 CERAMIC 47pF 5% 50V
C767 1-162-115-00 CERAMIC 330pF 10% 2KV
C768 1-126-964-11 ELECT 10µF 20% 50V
C769 1-161-830-00 CERAMIC .0047µF 500V
C770 1-107-662-11 ELECT 22µF 20% 250V
CONNECTOR
* CN761 1-564-508-11 PLUG,CONNECTOR 5P
* CN762 1-564-512-11 PLUG,CONNECTOR 9P
CN763 1-785-879-11 CONNECTOR, ONE TOUCH
CN764 1-695-915-11 TAB (CONTACT)
CN765 1-695-915-11 TAB (CONTACT)
! CN766 1-251-182-11 SOCKET, CRT
DIODE
D761 8-719-991-33 DIODE 1SS133T-77
D762 8-719-991-33 DIODE 1SS133T-77
D763 8-719-991-33 DIODE 1SS133T-77
D764 8-719-991-33 DIODE 1SS133T-77
D765 8-719-991-33 DIODE 1SS133T-77
COIL
L761 1-414-188-41 INDUCTOR 68µH
L762 1-412-911-11 FERRITE 0µH
NEON LAMP
NL761 1-517-778-21 LAMP, NEON
TRANSISTOR
Q761 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q762 8-729-326-11 TRANSISTOR 2SC3271F-N
Q763 8-729-119-76 TRANSISTOR 2SA1309A-QRSTA
Q764 8-729-200-17 TRANSISTOR 2SA1091O-TPE2
RESISTOR
R761 1-219-743-11 CARBON 100 5% 1/2W
R762 1-260-132-11 CARBON 560K 5% 1/2W
R763 1-247-807-31 CARBON 100 5% 1/4W
R764 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R765 1-247-807-31 CARBON 100 5% 1/4W
R766 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R767 1-249-393-11 CARBON 10 5% 1/4W
R768 1-249-418-11 CARBON 1.2K 5% 1/4W
R770 1-249-404-00 CARBON 82 5% 1/4W
R771 1-249-426-11 CARBON 5.6K 5% 1/4W
R772 1-249-435-11 CARBON 33K 5% 1/4W
R773 1-260-328-11 CARBON 1K 5% 1/2W
R775 1-249-425-11 CARBON 4.7K 5% 1/4W
R776 1-260-133-11 CARBON 680K 5% 1/2W
R777 1-260-328-11 CARBON 1K 5% 1/2W
R778 1-259-880-11 CARBON 2.2M 5% 1/4W
CG CB
