KP- 43T85T / 53SV85T / 61SV85T
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
R779 1-260-087-11 CARBON 100 5% 1/2W
R783 1-412-911-11 FERRITE 0µH
SPARK GAP
SG761 1-519-422-11 GAP, SPARK
SG762 1-517-729-31 GAP, SPARK
FA
* A-1241-390-A FA BOARD, MOUNTED
CAPACITOR
! C6001 1-104-706-11 MYLAR 0.22µF 20% 250V
! C6002 1-104-706-11 MYLAR 0.22µF 20% 250V
C6003 1-119-886-51 CERAMIC 470pF 10% 250V
C6005 1-119-886-51 CERAMIC 470pF 10% 250V
C6010 1-119-894-51 CERAMIC 2200pF 20% 250V
C6011 1-119-894-51 CERAMIC 2200pF 20% 250V
C6012 1-119-894-51 CERAMIC 2200pF 20% 250V
CONNECTOR
* CN6001 1-580-689-11 PIN,CONNECTOR (PC BOARD) 4P
CN6002 1-580-843-11 PIN,CONNECTOR (POWER)
CN6003 1-695-915-11 TAB (CONTACT)
* CN6004 1-580-689-11 PIN,CONNECTOR (PC BOARD) 4P
* CN6005 1-691-291-11 PIN,CONNECTOR (PC BOARD) 5P
* CN6006 1-691-960-11 PIN,CONNECTOR (PC BOARD) 3P
CN6007 1-695-915-11 TAB (CONTACT)
DIODE
! D6001 8-719-510-53 DIODE D4SB60L-F
FUSE
! F6001 1-532-506-51 FUSE 6.3A/250V
FUSE HOLDER
FH6001 1-533-223-11 HOLDER, FUSE
FH6002 1-533-223-11 HOLDER, FUSE
COIL
! L6001 1-424-248-11 TRANSFORMER, LINE FILTER
! L6002 1-424-248-11 TRANSFORMER, LINE FILTER
RESISTOR
R6001 1-218-265-11 METAL 8.2M 5% 1W
! R6002 1-219-512-11 CARBON 2.2M 5% 1/2W
! R6003 1-240-881-11 CMT- 0.82 5% 20W
! R6004 1-205-998-11 CEMENTED 1 5% 10W
! R6005 1-240-881-11 CMT- 0.82 5% 20W
VARISTOR
! VD6001 1-801-073-31 VARISTOR TNR14V471K660
VD6003 1-803-614-11 VARISTOR
A
* A-1298-990-A A BOARD, COMPLETE
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C002 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C003 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C004 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C005 1-126-935-11 ELECT 470µF 20% 6.3V
C006 1-126-960-11 ELECT 1µF 20% 50V
C015 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C016 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C039 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C040 1-126-916-11 ELECT 1000µF 20% 6.3V
C041 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C042 1-126-960-11 ELECT 1µF 20% 50V
C044 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C066 1-117-720-11 CERAMIC CHIP 4.7µF 10V
C072 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C080 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
C081 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
C082 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
C085 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C086 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C087 1-126-964-11 ELECT 10µF 20% 50V
C091 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
C093 1-104-665-11 ELECT 100µF 20% 25V
C094 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C098 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
CB
FA
A
