Sony MHC-V6D Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MHC-V6D
96
R289 1-218-937-11 METAL CHIP 47 5% 1/16W
R290 1-218-937-11 METAL CHIP 47 5% 1/16W
R291 1-218-937-11 METAL CHIP 47 5% 1/16W
R292 1-218-937-11 METAL CHIP 47 5% 1/16W
R293 1-218-937-11 METAL CHIP 47 5% 1/16W
R294 1-218-977-11 METAL CHIP 100K 5% 1/16W
R295 1-218-937-11 METAL CHIP 47 5% 1/16W
R297 1-218-965-11 METAL CHIP 10K 5% 1/16W
R298 1-218-965-11 METAL CHIP 10K 5% 1/16W
R300 1-218-965-11 METAL CHIP 10K 5% 1/16W
R301 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R302 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R304 1-218-977-11 METAL CHIP 100K 5% 1/16W
R305 1-218-990-81 SHORT CHIP 0
R306 1-218-965-11 METAL CHIP 10K 5% 1/16W
R307 1-218-990-81 SHORT CHIP 0
R308 1-218-941-81 METAL CHIP 100 5% 1/16W
R309 1-218-941-81 METAL CHIP 100 5% 1/16W
R310 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R312 1-218-953-11 METAL CHIP 1K 5% 1/16W
R313 1-218-953-11 METAL CHIP 1K 5% 1/16W
R316 1-218-953-11 METAL CHIP 1K 5% 1/16W
R317 1-218-953-11 METAL CHIP 1K 5% 1/16W
R319 1-218-965-11 METAL CHIP 10K 5% 1/16W
R321 1-218-941-81 METAL CHIP 100 5% 1/16W
R322 1-216-864-11 SHORT CHIP 0
R323 1-218-953-11 METAL CHIP 1K 5% 1/16W
R324 1-216-864-11 SHORT CHIP 0
R326 1-216-864-11 SHORT CHIP 0
R327 1-218-937-11 METAL CHIP 47 5% 1/16W
R328 1-216-798-11 METAL CHIP 12 5% 1/10W
R329 1-216-864-11 SHORT CHIP 0
R330 1-218-967-11 METAL CHIP 15K 5% 1/16W
R331 1-218-937-11 METAL CHIP 47 5% 1/16W
R332 1-250-483-11 METAL CHIP 330 1% 1/16W
* R334 1-250-543-11 METAL CHIP 100K 1% 1/16W
R335 1-218-990-81 SHORT CHIP 0
R337 1-218-990-81 SHORT CHIP 0
R339 1-250-512-11 METAL CHIP 5.1K 1% 1/16W
R340 1-218-937-11 METAL CHIP 47 5% 1/16W
R342 1-218-937-11 METAL CHIP 47 5% 1/16W
R343 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R344 1-218-941-81 METAL CHIP 100 5% 1/16W
R345 1-218-941-81 METAL CHIP 100 5% 1/16W
R346 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R347 1-218-990-81 SHORT CHIP 0
R348 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R349 1-218-941-81 METAL CHIP 100 5% 1/16W
R350 1-218-990-81 SHORT CHIP 0
R351 1-218-965-11 METAL CHIP 10K 5% 1/16W
R352 1-218-941-81 METAL CHIP 100 5% 1/16W
R354 1-218-990-81 SHORT CHIP 0
R355 1-218-990-81 SHORT CHIP 0
R356 1-218-937-11 METAL CHIP 47 5% 1/16W
R357 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R358 1-218-941-81 METAL CHIP 100 5% 1/16W
R359 1-218-953-11 METAL CHIP 1K 5% 1/16W
R360 1-218-941-81 METAL CHIP 100 5% 1/16W
R361 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R362 1-218-965-11 METAL CHIP 10K 5% 1/16W
R363 1-218-990-81 SHORT CHIP 0
R364 1-218-990-81 SHORT CHIP 0
R365 1-218-937-11 METAL CHIP 47 5% 1/16W
R366 1-218-990-81 SHORT CHIP 0
R367 1-218-941-81 METAL CHIP 100 5% 1/16W
R368 1-250-475-11 METAL CHIP 150 1% 1/16W
R369 1-218-933-11 METAL CHIP 22 5% 1/16W
* R370 1-250-489-11 METAL CHIP 560 1% 1/16W
R371 1-216-864-11 SHORT CHIP 0
R372 1-218-965-11 METAL CHIP 10K 5% 1/16W
R373 1-216-864-11 SHORT CHIP 0
R374 1-218-965-11 METAL CHIP 10K 5% 1/16W
R375 1-218-990-81 SHORT CHIP 0
R376 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R377 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R378 1-216-864-11 SHORT CHIP 0
R379 1-218-933-11 METAL CHIP 22 5% 1/16W
R380 1-218-933-11 METAL CHIP 22 5% 1/16W
R381 1-218-965-11 METAL CHIP 10K 5% 1/16W
R382 1-218-965-11 METAL CHIP 10K 5% 1/16W
R383 1-216-864-11 SHORT CHIP 0
R384 1-216-864-11 SHORT CHIP 0
R385 1-216-864-11 SHORT CHIP 0
R386 1-216-295-91 SHORT CHIP 0
R387 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R401 1-218-965-11 METAL CHIP 10K 5% 1/16W
R402 1-218-970-81 METAL CHIP 27K 5% 1/16W
R404 1-257-362-21 METAL CHIP 1 5% 1/2W
R406 1-218-990-81 SHORT CHIP 0
R407 1-218-990-81 SHORT CHIP 0
R408 1-218-965-11 METAL CHIP 10K 5% 1/16W
R409 1-218-965-11 METAL CHIP 10K 5% 1/16W
R410 1-218-965-11 METAL CHIP 10K 5% 1/16W
R411 1-218-965-11 METAL CHIP 10K 5% 1/16W
R415 1-218-970-81 METAL CHIP 27K 5% 1/16W
R418 1-218-967-11 METAL CHIP 15K 5% 1/16W
R421 1-218-941-81 METAL CHIP 100 5% 1/16W
R422 1-218-973-11 METAL CHIP 47K 5% 1/16W
* R423 1-250-572-11 METAL CHIP 15 1% 1/10W
R424 1-218-977-11 METAL CHIP 100K 5% 1/16W
* R425 1-250-572-11 METAL CHIP 15 1% 1/10W
* R426 1-250-572-11 METAL CHIP 15 1% 1/10W
* R427 1-250-572-11 METAL CHIP 15 1% 1/10W
* R428 1-250-572-11 METAL CHIP 15 1% 1/10W
R429 1-218-977-11 METAL CHIP 100K 5% 1/16W
* R430 1-250-572-11 METAL CHIP 15 1% 1/10W
R431 1-218-973-11 METAL CHIP 47K 5% 1/16W
R432 1-218-941-81 METAL CHIP 100 5% 1/16W
R433 1-216-295-91 SHORT CHIP 0
R451 1-218-941-81 METAL CHIP 100 5% 1/16W
R452 1-218-965-11 METAL CHIP 10K 5% 1/16W
R453 1-218-977-11 METAL CHIP 100K 5% 1/16W
R454 1-218-965-11 METAL CHIP 10K 5% 1/16W
R455 1-218-965-11 METAL CHIP 10K 5% 1/16W
R456 1-218-953-11 METAL CHIP 1K 5% 1/16W
R457 1-218-953-11 METAL CHIP 1K 5% 1/16W
R458 1-218-990-81 SHORT CHIP 0
* R460 1-250-491-11 METAL CHIP 680 1% 1/16W
R462 1-218-941-81 METAL CHIP 100 5% 1/16W
R463 1-218-969-11 METAL CHIP 22K 5% 1/16W
ARAGON

Sony MHC-V6D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	5 Ω
Bass reflex	-
Speaker type	3-way
RMS rated power	1440 W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display type	LCD
Audio (L/R) in	1
USB 2.0 ports quantity	2
Analog signal format system	NTSC, PAL
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	ENG, CHI (SIMPL), THA, CHI (TR)
Disc types supported	CD-RW, DVD-R, DVD, CD, DVD+R, DVD+R DL, CD-R, DVD+RW, DVD-RW
Audio formats supported	WMA, MP3
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Equalizer modes	Custom, Pop, Flat, Rap, Rock

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
Package depth	417 mm
Package width	972 mm
Package height	381 mm
Package weight	21000 g
