Sony MPK-THG - Service Manual Supplement; Change of Repair Parts Overview

MPK-THG
SERVICE MANUAL
MPK-THG
US Model
Canadian Model
AEP Model
Chinese Model
Sony EMCS Co.
9-852-612-83
2009D0500-1
© 2009.4
Published by Kohda TEC
Page Former New
Ref. No. Part No. DescriptionRef. No. Part No. Description
5 4-119-160-01 SLIDER (C), BUCKLE
6 4-115-562-01 COVER, BUCKLE
54 X-2342-708-1 FRONT CASE ASSY (SERVICE)
2
5 4-119-160-02 SLIDER (C), BUCKLE
6 4-115-562-02 COVER, BUCKLE
54 X-2342-708-2 FRONT CASE ASSY (SERVICE)
82 4-128-054-01 SHEET, LIGHT INTERCEPTION
3
Ver. 1.2 2009.04
72
73
72
82
73
*
SUPPLEMENT-2
File this supplement with the service manual.
(09-008)
• Change of Repair Parts
& : Points added portion.
SECTION 1
EXPLODED VIEWS
