Applying Special Effects (Lighting and Recursive Effects)
Knob
Parameter
Adjustment
Setting values
1
Shape Ptn
Shape pattern
1 to 2
a)
2
Size
Shape size
0.00 to 24.00
3
Deform
Amount of
shape
deformation
0.00 to 100.00
b)
4
Soft
Softness of
shape pattern
0.00 to 100.00
5
Angle
Angle of shape
pattern rotation
–8.00 to +8.00
c)
Knob
Parameter
Adjustment
Setting values
1
Offset
Offset from
center position
(radius)
–24.00 to
+24.00
2
Radius
Radius of ring
0.00 to 6.00
3
Angle
Rotation angle
of ring
–8.00 to +8.00
a)
(page 409) in the Appendix.
Chapter
11
DME
Operations
the light effect is not applied to the background, even if
you select BKGD or Both.
• If the setting of [Brilliancy] in the <Fill Source> group
of the Light Color Adjust menu (see page 343) is 100.00,
the light effect is not applied to the background, even if
you select BKGD or Both.
• When the global effect Combiner is set to Mix or Depth,
the light effect is not applied to the background, even if
you select BKGD or Both.
To select Surface Flat
Press [Surface Flat], turning it on.
If you have selected anything other than Flat in the
<Surface Select> group of the Spot Lighting menu, the
part corresponding only to the surface being struck by the
currently set light from the light source is shown in the
same way as if Flat had been selected.
To set the shape of the light
1 Press [Shape], turning it on.
2 Set the following parameters.
SD format
Knob
Parameter
Adjustment
Setting values
1
Shape Ptn
Shape pattern
1 to 2
a)
2
Size
Shape size
0.00 to 6.00
3
Deform
Amount of
shape
deformation
0.00 to 100.00
b)
4
Soft
Softness of
shape pattern
0.00 to 100.00
5
Angle
Angle of shape
pattern rotation
–8.00 to +8.00
c)
a) For more information about the shape patterns, see “Shape Patterns”
(page 409) in the Appendix.
b) 0 is a round shape, and 100 is the shape of the pattern. Smaller values
make the pattern more rounded.
c) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction.
HD format
c) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction.
To rotate the shape pattern
1 Press [Shape Speed], turning it on.
The display on knob 5 that was visible when [Shape]
was selected changes.
2 Set the following parameter.
Knob
Parameter
Adjustment
Setting values
5
Speed
Rotation
direction and
speed
–100.00 to
+100.00
a)
a) –100.00 is four rotations per second in the counterclockwise
direction, and +100.00 is four rotations per second in the clockwise
direction. 0.00 stops the rotation.
To change the light to a ring shape
Notes
If you select Parallel or Whole (see page 340) in the <Spot
Mode> group and shaping is disabled, the Ring parameter
cannot be set.
1 Press [Ring], turning it on.
2 Set the following parameter.
SD format
Knob
Parameter
Adjustment
Setting values
1
Offset
Offset from
center
position
(radius)
–6.00 to +6.00
2
Radius
Radius of
ring
0.00 to 6.00
3
Angle
Rotation
angle of ring
–8.00 to +8.00
a)
a) –1.00 is one rotation in the counterclockwise direction and +1.00 is
one rotation in the clockwise direction.
Notes
There is no Radius setting when Line is selected in the
<Spot Mode> group.
HD format
a) For more information about the shape patterns, see “Shape Patterns”
b) 0 is a round shape, and 100 is the shape of the pattern. Smaller values
make the pattern more rounded.
