50
MZ-G750/R700
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• CAPACITORS
uF : µF
• COILS
uH : µH
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• Abbreviation
CET : East European & CSI model
EE : East European model
FR : French model
HK : Hong Kong model
JE : Tourist model
CND : Canadian model
AUS : Australian model
AR : Argentina model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
CH : Chinese model
TW : Taiwan model
KR : Korean model
* A-3323-650-A MAIN BOARD, COMPLETE (R700:CND,AEP,UK,E,
AUS,EE,JE,FR,AR,HK,CH,TW,KR)
* A-3323-652-A MAIN BOARD, COMPLETE (G750:AEP,UK,E,AUS,
CET,JE,FR,HK,KR)
* A-3323-694-A MAIN BOARD, COMPLETE (R700:US)
* A-3323-703-A MAIN BOARD, COMPLETE (G750:US)
*********************
3-222-837-01 SPRING, BATTERY COIL
3-318-382-01 SCREW (1.7X3), TAPPING
< CAPACITOR >
C101 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
(US)
C101 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
(EXCEPT US)
C102 1-164-942-11 CERAMIC CHIP 0.0068uF 10% 16V
C104 1-135-868-11 TANTAL. CHIP 220uF 20% 2.5V
C105 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C106 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C110 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C111 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C112 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C113 1-131-862-11 TANTAL. CHIP 47uF 20% 4V
C116 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C117 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C118 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C201 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
(US)
C201 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
(EXCEPT US)
C202 1-164-942-11 CERAMIC CHIP 0.0068uF 10% 16V
C204 1-135-868-11 TANTAL. CHIP 220uF 20% 2.5V
C205 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C206 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C210 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C211 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C212 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C213 1-131-862-11 TANTAL. CHIP 47uF 20% 4V
C216 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C217 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C218 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C301 1-131-862-11 TANTAL. CHIP 47uF 20% 4V
C302 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C305 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C306 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C307 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C308 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C309 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C310 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C311 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C312 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C314 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C315 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C316 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C317 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C318 1-131-862-11 TANTAL. CHIP 47uF 20% 4V
C319 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C320 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C321 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C322 1-131-862-11 TANTAL. CHIP 47uF 20% 4V
C323 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C324 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C325 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C326 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C327 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C330 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C331 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C332 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C334 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C335 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C336 1-164-933-11 CERAMIC CHIP 220PF 10% 16V
C340 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C501 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C502 1-127-772-11 CERAMIC CHIP 0.033uF 10% 10V
C503 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C504 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C505 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C506 1-127-772-11 CERAMIC CHIP 0.033uF 10% 10V
C507 1-127-772-11 CERAMIC CHIP 0.033uF 10% 10V
C508 1-164-938-11 CERAMIC CHIP 0.0015uF 10% 16V
C509 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C510 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 16V
C511 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 16V
C512 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C513 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 16V
C514 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C515 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C516 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C518 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C519 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
