6-7
When External Input, No Audio Output
DISC PLAY Audio Out
is normal?
Check 'When Playing Disc, No Audi o Output'
YES
NO
Check JACK JK701,JK702 and other circuits
IC702 ñ 17,18pin
No Audio Signal input ?
YES
NO
When AV1 Input
REAR JACK is okay?
YES
NO
Check ADC Data path :IC702 - 6pin
=> IC503 -5pin => IC503 -6pin => IC301 -199pin
IC703,704 - 7pin
Audio swiching is okay ?
YES
NO
Check IC703, IC704 (AUDIO SWITCH)
& Check Control signal from MICOM IC501
Tuner - 2pin : High, 4pin : Low
AV1 - 2pin : High, 4pin : High
AV2 - 2pin : Low , 4pin : Low
Check signal path from RCA JACK to IC703,704
When AV2 Input
PIM02,PMI02 -27,29p in
are okay?
YES
NO
Check Connector PIM02 & PMI02
When AV2 Input
PMJ01,PJM01-2,3pin
are okay?
YES
NO
Check Connector PMJ01 & PJM01 and Cable
