7-1
RDR-GX210
NOTE:
• -XX and -X mean standardized parts, so they may
have some difference from the original one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• The mechanical parts with no reference number in
the exploded views are not supplied.
• Accessories and packing materials are given in the
last of the electrical parts list.
SECTION 7
REPAIR PARTS LIST
7-1. EXPLODED VIEWS
7-1-1. CABINET AND MAIN FRAME SECTION
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
250 9-885-077-76 CASE, TOP (EXCEPT AEP1: BLACK)
250 9-885-079-34 CASE, TOP (AEP1: BLACK)
251 1-479-164-11 REMOTE COMMANDER (RMT-D215P)
252 2-187-643-21 DOOR (RW2), SLIDE (for RMT-D215P)
253 3-071-119-91 COVER, BATTERY (for RMT-D215P)
266 9-885-078-05 FAN, DC
300 9-885-079-14 POWER CORD (AEP1: BLACK, UK)
300 9-885-079-15 POWER CORD (AEP1: SILVER, AEP2)
451 3-066-225-01 SONY BADGE (5-A)
452 9-885-077-95 SCREW, 3X10
453 9-885-079-06 CABLE, FLAT
463 9-885-077-75 SCREW, 3X8
465 9-885-077-98 SCREW, 3X10BK
467 9-885-077-74 SIDE SCREW, 3X8 (EXCEPT AEP1: BLACK)
467 9-885-079-33 SIDE SCREW, 3X8 (AEP1: BLACK)
468 9-885-077-99 SCREW, 3X20
469 9-885-078-07 SCREW, 3X6.5
470 9-885-078-08 SCREW, 3X24
A43 A-1107-507-A FRONT PANEL ASSY (UK)
A43 A-1110-125-A FRONT PANEL ASSY (AEP1: SILVER, AEP2)
A43 A-1110-320-A FRONT PANEL ASSY (AEP1: BLACK)
A47 A-1107-516-A SMPS BOARD, COMLETE (AEP1: BLACK, UK)
A47 A-1110-302-A SMPS BOARD, COMLETE
(AEP1: SILVER, AEP2)
A46 A-1107-517-A MAIN BOARD, COMLETE
A60 A-1107-514-A DECK ASSY, VIDEO
TU701 9-885-078-86 TUNER TADM-M901D (EXCEPT AEP1: SILVER)
TU701 9-885-078-87 TUNER TADM-S101D (AEP1: SILVER)
AEP1: France, Germany, Italy, Swiss, Belgie, Nether lands, Austria
AEP2: Spain, Portugal, Denmark, N.Euro (Hungary, Czech, Poland, Greece)
4
5
2
2
5
0
T
U
701
A4
6
4
69
4
69
252
453
253
251
4
6
7
4
6
3
4
6
9
4
6
9
4
6
5
470
4
6
9
45
2
45
2
4
5
2
4
5
2
4
68
26
6
4
6
7
4
6
5
4
6
5
A60
A43
451
4
6
3
4
6
3
A47
3
0
0
4
6
5
not supplied
not supplied
not supplied
not supplied
not supplied
not
supplied
not
supplied
not
supplied
not supplied
not supplied
not supplied
not
supplied
not
supplied
