7-3
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Not all of the parts are listed.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
7-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
AEP1: France, Germany, Italy, Swiss, Belgie, Nether lands, Austria
AEP2: Spain, Portugal, Denmark, N.Euro (Hungary, Czech, Poland, Greece)
KEY BOARD
**********
< LED >
LD1 9-885-078-31 LED SA3417 (TIMER REC)
LD2 9-885-066-42 LED SY3517 (PROGRESSIVE)
< IC >
RC901 9-885-046-90 IC TSOP2240SB1
< TRANSISTOR >
Q951 9-885-039-09 TRANSISTOR KSR1003
Q953 9-885-039-09 TRANSISTOR KSR1003
< SWITCH >
SW901 1-572-184-21 SWITCH, TACT (>)
SW902 1-572-184-21 SWITCH, TACT (.)
SW903 1-572-184-21 SWITCH, TACT (PROGRAM+)
SW904 1-572-184-21 SWITCH, TACT (PROGRAM -)
SW905 1-572-184-21 SWITCH, TACT (A)
SW906 1-572-184-21 SWITCH, TACT (H)
SW907 1-572-184-21 SWITCH, TACT (X)
SW908 1-572-184-21 SWITCH, TACT (x)
SW909 1-572-184-21 SWITCH, TACT (zREC)
I/O BOARD
*********
< DIODE >
D506 8-719-084-78 DIODE KDS121
ZD701 9-885-078-28 DIODE Z02W6.8V
ZD702 9-885-078-28 DIODE Z02W6.8V
ZD703 9-885-078-28 DIODE Z02W6.8V
ZD704 9-885-078-28 DIODE Z02W6.8V
ZD705 9-885-078-28 DIODE Z02W6.8V
ZD706 9-885-078-28 DIODE Z02W6.8V
ZD707 9-885-078-28 DIODE Z02W6.8V
ZD708 9-885-078-28 DIODE Z02W6.8V
ZD709 9-885-078-28 DIODE Z02W6.8V
ZD710 9-885-078-28 DIODE Z02W6.8V
ZD711 9-885-078-28 DIODE Z02W6.8V
ZD712 9-885-078-28 DIODE Z02W6.8V
ZD713 9-885-078-28 DIODE Z02W6.8V
ZD714 9-885-078-28 DIODE Z02W6.8V
ZD715 9-885-078-28 DIODE Z02W6.8V
ZD716 9-885-078-28 DIODE Z02W6.8V
ZD717 9-885-078-28 DIODE Z02W6.8V
ZD718 9-885-078-28 DIODE Z02W6.8V
ZD719 9-885-078-28 DIODE Z02W6.8V
ZD720 9-885-078-28 DIODE Z02W6.8V
ZD721 9-885-078-28 DIODE Z02W6.8V
ZD722 9-885-078-28 DIODE Z02W6.8V
ZD723 9-885-078-28 DIODE Z02W6.8V
ZD724 9-885-078-28 DIODE Z02W6.8V
ZD725 9-885-078-28 DIODE Z02W6.8V
ZD726 9-885-078-28 DIODE Z02W6.8V
ZD727 9-885-078-28 DIODE Z02W6.8V
ZD728 9-885-078-28 DIODE Z02W6.8V
ZD729 9-885-078-28 DIODE Z02W6.8V
ZD730 9-885-078-28 DIODE Z02W6.8V
ZD731 9-885-078-29 DIODE Z02W13V
ZD732 9-885-078-28 DIODE Z02W6.8V
ZD733 9-885-078-29 DIODE Z02W13V
ZD734 9-885-078-28 DIODE Z02W6.8V
ZD735 9-885-078-28 DIODE Z02W6.8V
ZD736 9-885-078-28 DIODE Z02W6.8V
< IC >
IC501 9-885-079-16 IC MICRO CONTROLLER
(AEP1:SILVER, AEP2)
IC502 8-759-971-11 IC PST529D
IC503 9-885-032-96 IC KIA7031P
IC504 8-759-098-19 IC MM1109XS
IC505 9-885-078-54 IC S524A60X51-SCT0
IC701 6-702-714-01 IC MSP3417G-QG-B8V3
IC702 9-885-078-51 IC CS4271-CZZ
IC703 8-759-450-93 IC NJM2521M-TE1
IC704 8-759-450-93 IC NJM2521M-TE1
IC705 8-759-274-73 IC NJM5532M (TE2)
IC706 9-885-078-50 IC MC33202DR2
IC707 9-885-078-50 IC MC33202DR2
IC708 9-885-041-64 IC MM1623XFBE
IC709 9-885-044-28 IC MM1443XJBE
IC710 8-759-567-33 IC MM1225XFBE
IC711 8-759-567-33 IC MM1225XFBE
